After a voltage drop the pump automatically starts up again with the speed last set,
or remains stopped if it had been stopped beforehand.
Overview of possible operating and error messages
If an error occurs, the motor switches off permanently and a message is displayed.
Exception: "Under voltage" if there is a failure or the power supply switches off. In this
case the motor restarts when the power supply is switched on again.
If an error occurs, the system must be disconnected from the power supply. See
chapter 2.2 of the original operating manual "Non self-priming and self-priming pumps
with/without plastic lanterns (AK version)".
03/2014
3
S
0
3
S
0
3
S
0
VG 766.2100.071
Switching behaviour "0" (stop)
The switching behaviour of the digital input "0"
can be changed (inverted) by using the menu
item "0".
"cL" means that the motor is stopped at a
closed contact.
"oP" means that the motor is stopped at an
open contact.
Resetting
The motor is reset to the factory setting when
the "INFO" button is pressed for at least 10
seconds. The motor stops and "rESEt" is
displayed.
The pump's current power requirements are
shown in watt (P XXX) in the display when the
"INFO" button is pressed.
The control unit's display switches off after
three minutes without action.
