10. Hydraulic diagrams
Recommended settings:
Parameter
Boiler temperature setpoint
Boiler temperature increase
Mixing valve 1 control
Max. mixing valve 1 temperature
Mixing valve 1 heating curve
Mixing valve 1 outdoor temperature compensation
Select mixing valve 1 thermostat
Diagram with two controlled heating circuits and DHW storage tank:
12
16
14
4
3
1. boiler,
2. heat exchanger,
3. controller module,
4. CT4 boiler temperature sensor,
6. boiler pump,
7. controller panel,
8. DHW pump,
9. mixing valve actuator,
10. CT4 mixing valve circuit temperature sensor,
Heating and ventilation
Setpoint
70-80°C
5-20°C
CH enabled
70°C
0.8 – 1.4
ON
ecoSTER T1
8
7
18
1
19
2
M
6 17
menu > boiler settings
menu > service settings > CH and DHW settings
menu > service settings > mixing valve 1 settings
menu > service settings > mixing valve 1 settings
menu > mixing valve 1 settings
menu > mixing valve 1 settings
menu > service settings > mixing valve 1 settings
cwu
10
13
9
10
11
9
11. mixing valve pump,
12. ecoSTER TOUCH room temperature controller with local thermostat
function or standard room thermostat,
13. CT4 DHW storage tank temperature sensor,
14. CT6-P weather compensator
15. independent safety thermostat disabling floor heating pump,
16. expansion tank
Platinum Bio ecoMAX 860P User Manual – EN 07.22
MENU
naczynie wzbiorcze
sieć wodociągowa
10
15
11
9
