8. Operation
62
Use Decrease value to set decrease in temperature for all time intervals. The
nighttime setback can be defined individually for every day of the week in
Schedule. Press a button to set the temperature setpoint reduction for a specific
time interval. Time intervals for 24 hours are set every 30 minutes.
TIME INTERVAL IS OMITTED WHEN DECREASE VALUE IS SET TO 0,
EVEN IF THE TIME RANGE IS SET.
8.22 Fuel level configuration
The controller uses fuel level sensor to monitor fuel level.
Set Fuel level sensor to Enabled in:
Service settings > Burner settings > Storage bin settings
When the fuel level is below the fuel level sensor, the controller will display the
following message:
„Low fuel level" and will continue feeding the fuel until the minimum fuel level
is reached. In fuel reserve mode, the remaining fuel (in kilograms) is displayed
in the main screen. If no fuel is added by the user, and the reserve is used, the
controller with shutdown the burner before the feeder is completely emptied.
Set Fuel level sensor to Disabled to disable the fuel level sensor.
8.23 Info
Info menu allows to view measured temperature and all installed devices.
IF THE MIXING VALVE EXTENSION MODULE IS INSTALLED,
ADDITIONAL INFO SCREENS ARE AVAILABLE. „CAL" MESSAGE IN THE
INFO SCREEN BY THE VALVE POSITION INDICATES CALIBRATION.
IN PROGRESS. WAIT UNTIL THE MIXING VALVE ACTUATOR
CALIBRATION IS FINISHED (CURRENT STATUS IS DISPLAYED).
8.24 Manual control
The controller allows to disable the devices, i.e. pump, feeder motor or fan
manually to check device functions and wiring.
MANUAL CONTROL MENU CAN BE ACCESSED IN STAND-BY MODE
ONLY, I.E. WITH BOILER SHUTDOWN.
Heating and ventilation
PROLONGED OPERATION OF THE FAN, FEEDER OR OTHER DEVICE
MAY RESULT IN A HAZARD.
8.25 Selecting heat source
The controller allows to select a single main heat source which supplies the
heating circuits. In the menu:
Boiler settings > Heat source
the following options are available: Burner-pellet, Grate-wood and Auxiliary
gas or oil burner.
8.26 GRATE - wood
It is available for boilers with wood firing option.
The controller allows grate operation with manual fuel feeding. The feeder is
disabled and the fan is enabled. Burner mode with pellet or grate mode with
wood can be selected in:
Boiler settings > Heat source
The fan runs at the following power levels:
Boiler settings > Power modulation at grate
Fan power setting in grate mode are different than in burner mode.
Grate mode parameters can be set in:
Service settings > Burner settings > Grate - wood
8.27 Operation with auxiliary feeder
The controller may control an auxiliary fuel feeder via H1 output (module A) or
H2 output (module B). When the fuel level sensor is tripped (contacts open),
the controller enables the auxiliary fuel feeder to fill the fuel storage bin for the
time set in Auxiliary fuel feeder operation time. The parameter can be set in:
Service settings > H output > H1/H2 output configuration
> Auxiliary feeder
If Auxiliary feeder operation time is set to zero, auxiliary feeder is disabled.
8.28 Oxygen sensor calibration
If the controller is fitted with an oxygen sensor, periodical calibration of the
oxygen sensor may be required. Shutdown the boiler to calibrate the oxygen
sensor. The oxygen sensor can be calibrated in shutdown mode only. The furnace
must be completely shut down. To start calibration, select:
Boiler settings > Oxygen sensor calibration
Calibration takes approx. 8 minutes.
8.29 Favourites menu
The following icon is displayed at the bottom bar.
Press to display quick access menu. Press and hold menu icon to add items to
the menu. Press and hold Favourites menu icon to remove item from the menu
and confirm.
