21 ¼"
77"
12"
12 ¼"
77"
12 ¼"
MODÈLE À UN TIROIR - ONE DRAWER MODEL
3.
Installation de la barre de soutien galvanisée en
L pour le meuble-lavabo.
Tracez une ligne à niveau à 21 ¼" du plancher et
une autre à la verticale pour indiquer le centre du
lavabo. Indiquez le centre sur la barre de soutien
puis alignez le bas de celle-ci à la ligne horizontale
et à celle du centre. Fixez-là aux emprises du mur avec les vis fournies
de 1 ½". S'il n'y a pas d'emprise, ouvrez le mur et renforcez-le.
3.
Install L-shaped metal support bracket for sink base.
Draw a level line 21 ¼" above the floor and a vertical line to indicate the
centre of the sink. Mark the centre on the support bracket and align its
base with the horizontal and centre lines. Fasten it to the wall studs with
the 1 ½" screws provided.
4.
Installation des barres de soutien pour la lingerie
(s'il y a lieu).
Tracez une ligne horizontale et à niveau à 12" du
plancher et une autre à 77" du plancher. Tracez
ensuite une ligne verticale pour indiquer le centre de
la lingerie. Indiquez le centre sur les deux barres de
soutien. Alignez le bas de la barre en Z sur la ligne
horizontale du haut et centrez avec la ligne verticale. Vissez-là aux
emprises du mur avec les vis 1 ½" fournies. S'il n'y a pas d'emprise,
ouvrez le mur et solidifiez le. Faites de même avec la barre galvanisée
en L à 12" du sol.
4.
Install metal brackets for linen cabinet (if applicable).
Draw a level horizontal line 12" above the floor and another 77" above
the floor. Then, draw a vertical line to indicate the centre of the linen
cabinet. Mark the centre on both metal brackets. Align the base of
the Z-shape metal bracket on the upper horizontal line and centre it
with the vertical line. Fasten it to the wall studs with the 1 ½" screws
provided. If there are no studs, open the wall and reinforce it. Repeat
for the lower L-shaped galvanized bracket 12" from the floor.
MODÈLE À 2 TIROIRS SUPERPOSÉS
MODEL WITH 2 SUPERPOSED DRAWERS
3.
Installation de la barre de soutien galvanisée en L
pour le meuble-lavabo.
Tracez une ligne à niveau à 12 ¼" du plancher et une
autre à la verticale pour indiquer le centre du lavabo.
Indiquez le centre sur la barre de soutien puis alignez
le bas de celle-ci à la ligne horizontale et à celle du centre. Fixez-là aux
emprises du mur avec les vis fournies de 1 ½". S'il n'y a pas d'emprise,
ouvrez le mur et renforcez-le.
3.
Install L-shaped metal support bracket for sink base.
Draw a level line 12 ¼" above the floor and a vertical line to indicate the
centre of the sink. Mark the centre on the support bracket and align its base
with the horizontal and centre lines. Screw it through the wall studs using
1 ½" screws provided. If there are no studs, open the wall and reinforce it.
4.
Installation des barres de soutien en aluminium pour la lingerie (s'il y a
lieu).
Tracez une ligne horizontale et à niveau à 12 ¼" du plancher et une
autre à 77" du plancher. Tracez ensuite une ligne verticale pour
indiquer le centre de la lingerie. Indiquez le centre sur les deux barres
de soutien. Alignez la barre en Z sur le bas de la ligne horizontale
du haut et centrez avec la ligne verticale. Vissez-là aux emprises du
mur avec les vis 1 ½" fournies. S'il n'y a pas d'emprise, ouvrez le mur et
renforcez-le. Faites de même avec la barre de soutien en L à 12 ¼" du sol.
4.
Install metal brackets for linen cabinet (if applicable).
Draw a level horizontal line 12" above the floor and another 77" above
the floor. Then, draw a vertical line to indicate the centre of the linen
cabinet. Mark the centre on both metal brackets. Align the base of
the Z-shape metal bracket with the upper horizontal line and centre
it on the vertical line. Fasten it to the wall studs with the 1 ½" screws
provided. If there are no studs, open the wall and reinforce it. Repeat for
the lower L-shaped metal bracket.
21 ¼"
9
