Attention: the chainsaw is delivered without oil. Refill before use or operation.
Check the oil level prior to each use and, if required, refill with chain saw oil.
During operation, regularly check the oil level through the oil level window (14).
4.10- Saw chain lubrication
To avoid premature wear of the tool, the chain and the guide bar must be lubricated homogeneously
throughout the operation.
The lubrication is automatic.
Never use the chainsaw if the chain is not lubricated. If the chain is dry, the entire cutting device may
become damaged.
It is therefore essential to check both the lubrication of the chain and the oil level before each use.
Never use the chainsaw when the oil level is below the level marked "Min."
- Minimum - If the oil level reaches the "min" line on the bottom edge of the gauge, add oil.
- Maximum - Add oil until the tank is filled.
4.11- Checking the automatic lubrication
Before starting operation, check the automatic lubrication of the chain and the oil level.
Switch on the chainsaw and place it on top of a clear colored surface.
Never leave the machine hit the ground.
For security reasons, keep it to about 20cm from the ground.
If an oil stain appears and grows on the ground, it means that the chain lubricating system is working
properly.
If no oil stain appears, try cleaning the lubrication hole (e in Fig3) and the anchor hole of the chain
adjusting pin. Remove all dust.
If the problem is not solved, contact the authorized service centre.
4.12- Saw Chain Oil
The lifetime of the chain and guide bar depends greatly on the quality of lubricant used.
Choose a chain lubricant that is environmental friendly.
Use only quality chainsaw oil without sticking additive for lubricating the saw chain and guide bar.
Do not use used or recycled oil, as it could damage the oil pump!
Used oil does not have the required lubricating properties for lubricating the saw chain and, in
addition, it is harmful for the environment.
Oils for saw chains stick when not being used for longer time. This can cause damage to oil
pump or parts leading the oil. Therefore, prior to each storage:
- Empty the oil from oil tank.
- Fill in the tank with little engine oil.
- Allow the chain saw to run for some time to enable the oil leadings and oil pump clean.
- Before other use of the chainsaw, refill the tank with oil for saw chains again.
Store oil in certified containers (such as Jerrycan).
4.13- Chain Brake
The chainsaw is equipped with a chain brake (front handle guard (3)) that reduces possibility of
injury due to kickback.
The brake is activated if pressure is applied against brake lever when, as in the event of kickback,
operator's hand strikes the lever. The chain movement and motor will stop abruptly in 0.15s when the
brake is actuated.
The purpose of the chain brake is to reduce the possibility of injury due to kickback; however, it
