Caractéristiques techniques
8.5 Description du matériel
Brochage de l'interface PEG (PCIe broche X16), X610
Signal
210
P12V
P12V
P12V
GND
SMB_CLK2
SMB_DATA2
GND
P3V3
n.c.
AUX_3V
WAKE2
n.c.
GND
PCIEX16_TX_P(15)
PCIEX16_TX_N(15)
GND
SDVO_CTRLCLK
GND
PCIEX16_TX_P(14)
PCIEX16_TX_N(14)
GND
GND
PCIEX16_TX_P(13)
PCIEX16_TX_N(13)
GND
GND
PCIEX16_TX_P(12)
PCIEX16_TX_N(12)
GND
n.c.
SDVO_CTRLDATA
GND
PCIEX16_TX_P(11)
PCIEX16_TX_N(11)
GND
GND
PCIEX16_TX_P(10)
PCIEX16_TX_N(10)
GND
GND
PCIEX16_TX_P(9)
PCIEX16_TX_N(9)
N° de N° de Signal
broche broche
B1 A1
B2 A2
B3 A3
B4 A4
B5 A5
B6 A6
B7 A7
B8 A8
B9 A9
B10 A10
B11 A11
B12 A12
B13 A13
B14 A14
B15 A15
B16 A16
B17 A17
B18 A18
B19 A19
B20 A20
B21 A21
B22 A22
B23 A23
B24 A24
B25 A25
B26 A26
B27 A27
B28 A28
B29 A29
B30 A30
B31 A31
B32 A32
B33 A33
B34 A34
B35 A35
B36 A36
B37 A37
B38 A38
B39 A39
B40 A40
B41 A41
B42 A42
Instructions de service, 03/2018, A5E32997459-AC
P12V
P12V
P12V
GND
n.c.
n.c.
n.c.
n.c.
P3V3
P3V3
PCIE_RESET_L
GND
PCIE0_ECLK
PCIE0_ECLK_N
GND
PCIEX16_RX_P(15)
PCIEX16_RX_N(15)
GND
n.c.
GND
PCIEX16_RX_P(14)
PCIEX16_RX_N(14)
GND
GND
PCIEX16_RX_P(13)
PCIEX16_RX_N(13)
GND
GND
PCIEX16_RX_P(12)
PCIEX16_RX_N(12)
GND
n.c.
n.c.
GND
PCIEX16_RX_P(11)
PCIEX16_RX_N(11)
GND
GND
PCIEX16_RX_P(10)
PCIEX16_RX_N(10)
GND
GND
