KitchenAid KFID500ESS Instructions D'utilisation page 9

Pan Detection
If the system cannot recognize the pan, or if the pan has been
removed from the surface cooking area, the "replace pan"
animation appears in the cooking area display as a reminder. See
the following illustration.
If the pan is not placed within 30 seconds, the zone(s) will switch
Off.
If a timer is running when a pan is removed, the countdown will
continue.
Control Lock
The Control Lock avoids unintended use of the surface cooking
areas.
If Control Lock is activated when power to the cooktop is off, the
cooktop is locked out, and the surface cooking areas cannot be
turned on by the cooktop touch controls.
If Control Lock is activated when power to the cooktop is on, all
keypads are locked out except for the Power and Off keypads.
To Lock Cooktop:
Touch and hold the CONTROL LOCK keypad for 5 seconds. After
5 seconds, a tone will sound and the indicator light above the
Control Lock keypad will light, indicating that the cooktop controls
are in the lockout position.
If the cooktop is in use when Control Lock is activated, cooking will
proceed as normal and any timers that have been set will continue
their countdown.
To Unlock Cooktop:
Touch and hold the CONTROL LOCK keypad for 5 seconds.
Performance Boost Function
This function allows you to increase the heat setting level above
the maximum heat setting "9" for 10 minutes or less.
NOTES:
Performance Boost function is available on only 1 surface
cooking area at a time within a zone. See the following
illustration for zones.
A
B
Zone 1
A. Surface cooking area 1
B. Surface cooking area 2
D
C
Zone 2
C. Surface cooking area 3
D. Surface cooking area 4
If you attempt to use Performance Boost on more than one
surface cooking area in the same zone, "P" will briefly flash in
the display, and the first surface cooking area selected for
Performance Boost will automatically be set back to the
highest power available setting. The last surface cooking area
selected will be set to Performance Boost.
1. Check that a surface cooking area has been selected.
2. Touch BOOST. "P" will appear in the display.
3. Touch BOOST when finished. The "P" will no longer be visible
in the display, and the Performance Boost function will no
longer be active. The surface cooking area turns back to the
highest available power level.
NOTE: The Performance Boost function may automatically
deactivate to keep the internal electronic components of the
cooktop from becoming too hot.
Timer
Use the cooktop timer to set times up to 90 minutes. The timer is
independent of any other control settings. A cooktop element
must be active in order for the cooktop timer to be used.
To Use:
1. Touch TIMER "+" or "-" keypad. "01" appears in the timer
display.
2. Touch the TIMER "+" keypad to increase the time in
1-minute increments.
OR
Touch the TIMER "-" keypad to decrease the time in
1-minute increments.
3. The timer will start to count down after a few seconds.
To change the time, touch the TIMER "+" or TIMER "-" keypad.
4. When the countdown is finished, "00" flashes and a tone will
sound.
NOTE: When the power is restored after an outage, the timer will
no longer be running.
Tones
Tones are audible signals, indicating the following:
One Tone
Valid keypad press.
Slider is moved to "0" power level.
Slider is moved to "Boost" power level.
Two Tones
Invalid keypad press.
Three Tones
End of Timer cycle.
Ceramic Glass
Clean the cooktop after each use to help avoid scratches, pitting,
abrasions and to condition the glass surface. Ceramic glass
cooktop cleaner and a cooktop scraper are also recommended for
stubborn soils. Do not use abrasive cleaners, cleaning pads or
harsh chemicals for cleaning. The Cooktop Care Kit Part Number
31605 contains all of the items needed to clean and condition your
ceramic glass cooktop. Refer to the "Range Care" section for
additional information.
IMPORTANT: To avoid permanent damage to the cooktop surface
and to make soils easier to remove, clean the cooktop after each
use to remove all soils.
9
