I. Kabelplan / Cable plan
230 V AC 50 Hz
1
NT 12 V
AC/DC
2
Controller
GCER 100
4
5
GCER 100
1 NYM-J 3 x 1,5 mm
2 J-Y (ST) Y 2 x 2 x 0,6 mm
3 Kabel / cable IQ lock - LIYY 12 x 0,14 mm
4 Kabel / cable GCER 100 - 10 m, LIYY 2 x 2 x 0,25 mm
5 Leerrohr/ empty conduit - ø 10 mm
22
NT 24 V
AC/DC
2
2
2
2
2
2
2
2
2
2
2
GEZE SecuLogic GCER 100
2
Elektrischer Türöffner/
electric strike
3
3
2
Haltemagnet/
holding magnet
5
5
