Foreo ESPADA Mode D'emploi page 3

Emissions test Emissions test
Actinic UV Risk Group 2
Near UV Risk Group 2
Blue-light Risk Group 1
Retinal Thermal Exempt Group
Retinal Thermal,
Exempt Group
weak visual stimulus
Corneal/ Lens IR Exempt Group
Spectral irradiance: 0.5lm. Maximum output of optical radiation: 75mW
CHARGING: Your FOREO device is rechargeable with its included USB cable. It is
recommended that IEC60950 standard power suppliers are used to charge the ESPADA
1.5 hours of charging delivers a full charge that will provide up to 100 30-second treatments.
While charging, the indicator will ash repeatedly. When the battery is full, the indicator will
emit a steady glow. When the battery is low, the indicator will start to ash repeatedly.
CAUTION: Before charging, make sure the charging port and charger are free from water. Do
NOT use your FOREO device while charging, and do NOT charge for more than 24 hours.
Never use the device or charger if they are damaged, and only use the charger supplied by
FOREO with the device. To reduce risk of electric shock, do not place the device where it can
fall into water or other liquid. If device accidentally falls into water when charging, unplug
immediately. The charging chord should be kept away from all heated surfaces. Never insert
any object into any openings of the device. Never operate this device if its chord or plug has
been damaged or is working improperly.
MAINTENANCE AND SAFETY: To keep your FOREO device in optimum condition, we
recommend cleaning the ESPADA 's treatment surface after each use. Clean the device with
TM
soap, rinse with warm water and dry with a soft, lint-free cloth. We recommend spraying the
device with FOREO's Silicone Cleaning Spray for optimal results. NEVER use cleaning products
that are silicone-based or containing alcohol, petrol or acetone as they may damage silicone.
ENVIRONMENTAL REQUIREMENTS
Emissions test Operation
Temperature 5 to 40 °C
Humidity 15 to 93% RH, non-condensing
Pressure 700 - 1060hPa
WARRANTY TERMS AND CONDITIONS
REGISTER WARRANTY: To activate your 2-Year Limited Warranty, register the number
provided on the FOREO Magnetic Card at www.foreo.com/support.
2-YEAR LIMITED WARRANTY: FOREO warrants this device for a period of TWO (2) YEARS
after the original date of purchase against defects due to faulty workmanship or materials
arising from Normal Use of the device. The warranty covers working parts that affect the
function of the device. It does NOT cover cosmetic deterioration caused by fair wear and tear,
or damage caused by accident, misuse or neglect. Any attempt to open or take apart the
device (or its accessories) will void the warranty. If you discover a defect and notify FOREO
during the warranty period, FOREO will, at its discretion, replace the device free of charge.
Claims under warranty must be supported by reasonable evidence that the date of the claim
is within the warranty period. To validate your warranty, please keep your original purchase
receipt together with these warranty conditions for the duration of the warranty period. To
claim your warranty, you must log in to your account at www.foreo.com then select the option
to make a warranty claim. Shipping costs are nonrefundable. This undertaking is in addition to
your statutory rights as a consumer and does not affect those rights in any way.
FOR AUSTRALIA-BASED CUSTOMERS ONLY: Our goods come with guarantees that cannot
be excluded under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure. Australia Of ce, FOREO Oceania,
Level 1, Suite 10, 1014 Doncaster Road, Doncaster East, VIC, 3109, Australia. TEL +61 (0) 448 885 779
DISPOSAL INFORMATION: Battery must be recycled or disposed of properly. Disposal of
old electronic equipment (applicable in the EU and other European countries with separate
waste collection systems). The crossed-out dustbin symbol indicates that this device should
not be treated as household waste, but rather be brought to the appropriate collection point
for recycling of electrical and electronic equipment. Please see back page for instructions on
how to remove the battery.
BATTERY CARE: It is recommended to regularly use the device to ensure proper performance.
The ESPADA should be fully charged at least every 3 months to maintain the battery.
TM
GUIDANCE AND MANUFACTURER'S DECLARATION: ELECTROMAGNETIC EMISSIONS
& IMMUNITY: Medical electrical equipment requires special precautions regarding EMC and
must be installed and put into service according to EMC information provided in this
document. Portable and mobile RF communications equipment can affect the medical
electrical equipment. This declaration currently applies to the ESPADA
Emissions test
UV emitted from this device
May result in eye or skin irritation
UV emitted from this device
May result in eye irritation
Not required
Not required
Not required
Not required
Storage and Transport
-10 to 50 °C
<=93% RH, non-condensing
700 - 1060hPa
TM device.
GUIDANCE AND MANUFACTURER'S DECLARATION: ELECTROMAGNETIC EMISSIONS:
The device is intended for use in the electromagnetic environment speci ed below. The
customer or the user of the device should assure that it is used in such an environment.
Emissions test Compliance
RF emissions
Group 1
CISPR 15
RF emissions
Group 2
CISPR 11
WARNINGS:
• This device should not be used adjacent to other high eld equipment or areas. If adjacent
use is necessary, the device should be observed to verify normal operation in the
.
TM
con guration in which it will be used.
• This device should not be used adjacent to high-frequency equipment. If the device is
adjacent to a short wave device or microwave device, the device's output may be unstable.
• The use of accessories other than those speci ed for the device is not recommended as it
may result in increased emissions or decreased immunity of the device.
• The device is intended for use in the electromagnetic environment speci ed below. The
customer or the user of the device should assure that the device is used in such an environment.
Immunity test IEC60601-1-2
test level
Electrostatic ± 6kV contact
Discharge(ESD)
IEC 61000-4-2
± 8kV air
Electromagnetic 3V/m
field susceptibility
IEC61000-4-3
Power frequency 3A/m
(50/60 HZ)
Magnetic field
IEC 61000-4-8
Radiated 40 dBµV/M (3M)
emission 30MHZ ~ 230MHZ
47 dBµV/M (3M)
230MHZ~ 1000MHZ
Field strengths from xed transmitters, such as base stations for radio (cellular/cordless),
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to xed RF transmitters, an electromagnetic site survey should be
considered. If the measured eld strength in the location in which the ESPADA
used exceeds the applicable RF compliance level above, the device should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as re-orienting or relocating the device.
NOTES: These guidelines may not apply in all situations. Electromagnetic propagation is affected.
RECOMMENDED SEPARATION DISTANCES BETWEEN PORTABLE AND MOBILE RF
COMMUNICATIONS EQUIPMENT AND THE DEVICE
The device is intended for use in an electromagnetic environment in which radiated
RF disturbances are controlled. The customer or the user of the device can help prevent
electromagnetic interference by maintaining a minimum distance between portable and
mobile RF communications equipment (transmitters) and the device as recommended below,
according to the maximum output power of the communication equipment.
Separation distance according to frequency of transmitter (m)
Rated maximum
output Power of
30MHZ to 80MHZ
transmitter (w)
0.01 d = 1.2√p
0.1 d = 1.2√p
1 d = 2.3√p
10 3.8
100 12
For transmitters rated at a maximum output not listed above, the recommended separation
distance (d) in meters (m) can be estimated using the equation application to the frequency of
the transmitter, where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacture.
NOTES: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and re ection from structures, objects and people.
4
Electromagnetic environment-guidance
The device is supplied by very low voltage Li-on battery.
Therefore, its RF emissions are very low and are not likely to
cause any interference in nearby electronic equipment.
The device does not need to use an AC adapter to
charge, so it's radiated power is very low.
Compliance level
Electromagnetic environment
guidance
± 6kV contact Floors should be wood, concrete or
ceramic tile. If floors are covered
with synthetic material, the relative
± 8kV air
humidity should be at least 30%.
3V/m Because it is not life-supporting
equipment, it does not use only
shield location.
3A/m Power frequency magnetic fields
should be at levels characteristic of a
typical location in a typical commercial
or hospital environment.
40 dBµV/M (3M) In all frequencies, the radiated
30MHZ ~ 230MHZ strength is less than limited value.
47 dBµV/M (3M)
230MHZ~ 1000MHZ
80MHZ to 800MHZ 800MHZ to 1000MHZ
d = 1.2√p d = 2.3√p
0.12 0.23
0.38 0.73
1.2 2.3
3.8 7.3
12 23
TM device is
5
