RIMOZIONE DEI PANNELLI LATERALI
REMOVING THE SIDE PANELS
For some maintenance operations, one or both
the side panels need to be removed.
To remove the left- and right-hand side panels,
operate as follows:
- Unscrew the screw (2).
- Lift the panel (1) releasing it from the upper
hooks
2

PRELIMINARY CONTROLS

A. Engine-transmission oil level
Note*: Check the oil level when the engine has
just been turned off and is still hot.
- Position the motorcycle on a flat surface in
vertical position.
- Remove the RH side panel as described in
the relative paragraph.
- Unscrew the dipstick (1) and remove it; clean
it with a cloth and reinsert it in the filling hole (2)
without screwing it back in, then remove it again
1
and check that the oil level is between the "MIN"
and "MAX" notches
- If you need to top up, pour in oil through
the hole (2) until reaching the correct level.
- Reinsert the dipstick and screw it back into
place.
1
2
1
Six Day
7 / EN
