3.19.6 Unsymmetrical working area with a narrow passage and a number of islands

2
Area 150 m
Timer 7 am - 5 pm
Monday, Wednesday,
Friday
Remote start - Rarely (factory setting)
Proportion
Remarks The guide wire must be placed along
the narrow passage to ensure that
the robotic lawnmower can with ease
locate the charging station from the
right hand side of the working area.
Select Proportion:
hand area is a small fraction of the to-
tal area. Make sure guide wire is laid
according to recommendations in
Laying and connecting the guide wi-
reà la page20
3.19.7 Three areas linked with two narrow passages
2
Area 600 m
ROB R1000 only.
Timer
7 am - 11 pm
Monday, Tuesday, Thursday, Friday
Remote start 1 - Rarely
Proportion
Remote start 2 - Rarely
Proportion
Remarks As the working area contains three
areas linked by two narrow passages,
Remote start 1 and Remote start 2
must be used to obtain an even mow-
ing result across the entire working
area. Available in ROB R800,
ROB R1000. Make sure guide wire is
laid according to recommendations in
Installation of the guide wireà la pa-
ge19
3.19.8 A secondary area
Area 200 + 50 m
Timer
7 am - 6 pm
Monday, Thursday,
Friday
Remote start - Rarely (factory setting)
Proportion
Remarks The secondary area is cut using the
MAN mode on Wednesday and Sa-
turday.
34 - Installation
/ 1600 sq. ft.
Rarely as the right
/ 4300 sq. ft. ROB R800,
2
/ 2200 + 550 sq. ft.
2 m / 7 ft
