DENOMINAZIONE – DENOMINATION – DESIGNATION
1 - Vite
2 - Maniglia
3 - Vite
4 - Coperchio Morsettiera
5 - O-ring
6 - Vite
7 - Cavo di alimentazione (2)
8 - Cavo di alimentazione
9 - Pressacavo
10 - Pressacavo
11 - Vite
12 - Supp. sup. con morsetttiera
13 - O-ring
14 - O-ring
15 - Statore avvolto
16 - Carcassa motore
17 - Vite
18 - O-ring
19 - Vite
20 - Supporto cuscinetto inf
21 - O-ring
22 - Tappo olio
23 - Lanterna allogg. tenuta
24 - O-Ring
25 - Coperchio tenuta Sup.
26 - Vite
27 - O-ring
28 - Vite
29 - Camera olio
30 - Tappo olio
31 - Vite
32 - O-ring
33 - O-ring
34 - Coperchio tenuta inf.
35 - Vite
37 - Corpo pompa
38 - Cuscinetto sup.
39 - Albero rotore
40 - Chiavetta
41 - Cuscinetto inf.
42 - Anello MIM
43 - Seeger
44 - Girante raffreddamento
45 - Seeger
46 - Tenuta superiore
47 - Tenuta inferiore
48 - Girante
49 - Rondella bloccaggio girante
50 - Vite
1 - Screw
2 - Handle
3 - Screw
4 - Cover terminal block
5 - O-ring
6 - Screw
7 - Feeding cable (2)
8 - Feeding cable
9 - Cable press
10 - Cable press
11 - Screw
12 - Support. With terminal block
13 - O-ring
14 - O-ring
15 - Stator with winding
16 - Motor case
17 - Screw
18 - O-ring
19 - Screw
20 - Lower bearing support.
21 - O-ring
22 - Oil plug
23 - Seal casing
24 - O-ring
25 - Upper mechanical seal cover
26 - Screw
27 - O-ring
28 - Screw
29 - Seal Housing
30 - Oil plug
31 - Screw
32 - O-ring
33 - O-ring
34 - Lower mechanical seal cover
35 - Screw
37 - Pump body
38 - Upper bearing
39 - Shaft with rotor
40 - Key
41 - Lower bearing (n°2)
42 - Spring ring MIM
43 - Spring ring
44 - Colling impeller
45 - Spring ring
46 - Upper mechanical seal
47 - Lower mechanical seal
48 - Impeller
49 - Washer fixing
50 - Screw
43
1 - Vis
2 - Poignée
3 - Vis
4 - Couvercle bornes de branchement
5 - Joint OR
6 - Vis
7 - Cable èlectrique (2)
8 - Cable èlectrique
9 - Prèsse-cable
10 - Prèsse-cable
11 - Vis
12 - Support bornes de branchement
13 - Joint OR
14 - Joint OR
15 - Stator avec bobinage
16 - Carcasse du moteur
17 - Vis
18 - Joint OR
19 - Vis
20 - Support roulement inf.
21 - Joint OR
22 - Bouchon d'huile
23 - Support garniture mècan. Sup.
24 - Joint OR
25 - Couvercle garniture mècan. Sup.
26 - Vis
27 - Joint OR
28 - Vis
29 - Chambre d'huile
30 - Bouchon d'huile
31 - Vis
32 - Joint OR
33 - Joint OR
34 - Couvercle garniture mècan. Inf.
35 - Vis
37 - Corps de pompe
- Roulement sup.
38
39 - Arbre avec rotor
40 - Clavette
41 - Roulement inf
42 - Anneau d'arrète MIM
43 - Anneau d'arrète
44 - Turbine de refridgement
45 - Anneau d'arrète
46 - Garniture mécanique sup.
47 - Garniture mécanique inf.
48 - Turbine
49 - Rondelle de fixage
50 - Vis
