POMPE ROTOMEC RS Serie Notice D'instructions page 39

DENOMINAZIONE – DENOMINATION – DESIGNATION
1 - Cavo di alimentazione
2 - Pressacavo
3 - Passacavo
4 - Collare serracavo
5 - Golfare
6 - Vite
7 - Coperchio motore
8 - O-ring
9 - Supporto cuscinetto sup.
10 - Vite
11 - O-ring
12 - Carcassa motore
13 - Statore avvolto
14 - Vite
15 - Coperchio cuscinetto inf
16 - O-ring
17 - Supporto cuscinetto inf
18 - Tappo olio
19 - Vite
20 - O-ring
21 - Vite
22 - Lanterna allogg. tenuta
23 - Vite
24 - O-Ring
25 - Corpo pompa
26 - Cuscinetto sup.
27 - Albero con rotore
28 - Chiavetta
29 - anello MIM
30 - Cuscinetto inf. (n°2)
31 - Ghiera bloccaggio cuscinetto
32 - Tenuta meccanica sup.
33 - Seeger
34 - Tenuta meccanica inf.
35 - Girante
36 - Rondella bloccaggio girante
37 - Vite
38 - O-ring
1 - Feeding cable
2 - Cable press
3 - Cable gland
4 - Cable clamp
5 - Screw eye
6 - Screw
7 - Casing cover
8 - O-Ring
9 - Upper bearing support
10 - Screw
11 - O-ring
12 - Motor case
13 - Stator with winding
14 - Screw
15 - Lower bearing cover
16 - O-ring
17 - Lower bearing support
18 - Oil plug
19 - Screw
20 - O-ring
21 - Screw
22 - Seal casing cover
23 - Screw
24 - O-ring
25 - Pump body
26 - Upper bearing
27 - Shaft with rotor
28 - Key
29 - Spring ring
30 - Lower bearing (n°2)
31 - Threaded lock bearing
32 - Upper mechanical seal
33 - Seeger
34 - Lower mechanical seal
35 - Impeller
36 - Washer fixing
37 - Screw
38 - O-ring
39
1 - Cable èlectrique
2 - Prèsse-cable
3 - Passe-cable
4 - Bague de blocage de cable
5 - Anneau a vis
6 - Vis
7 - Couvercle du moteur
8 - Joint OR
9 - Support roulement sup.
10 - Vis
11 - Joint OR
12 - Carcasse du moteur
13 - Stator avec bobinage
14 - Vis
15 - Couvercle roulement inf.
16 - Joint OR
17 - Support roulement inf
18 - Bouchon d'huile
19 - Vis
20 - Joint OR
21 - Vis
22 - Couvercle garniture mècan.
23 - Vis
24 - Joint OR
25 - Corps de pompe
26 - Roulement sup.
27 - Arbre avec rotor
28 - Clavette
29 - Anneau d'arrète MIM
30 - Roulement inf. (n°2)
31 - Anneau d'arrète roulement
32 - Garniture mécanique sup.
33 - Anneau d'arrète
34 - Garniture mécanique inf.
35 - Turbine
36 - Rondelle de fixage
37 - Vis
38 - Joint OR
