DENOMINAZIONE – DENOMINATION – DESIGNATION
1 - Cavo di alimentazione x2
2 - Pressacavo x2
3 - Passacavo x2
4 - Collare serracavo x2
5 - Cavo protezioni termiche
6 - Pressacavo
7 - Passacavo
8 - Collare serracavo
9 - Maniglia
10 - Vite
11 - Vite
12 - Coperchio motore
13 - O-ring
14 - Supporto cuscinetto sup.
15 - O-ring
16 - Statore avvolto
17 - Carcassa motore
18 - Vite
19 - O-ring
20 - Vite
21 - Coperchio cuscinetto inf
22 - Supporto cuscinetto inf
23 - Vite
24 - Tappo olio
25 - O-ring
26 - Vite
27 - Lanterna allogg. tenuta
28 - Vite
29 - Corpo pompa
30 - Cuscinetto sup.
31 - Albero con rotore
32 - Chiavetta
33 - Anello MIM
34 - Cuscinetto inf.
35 - Seeger
36 - Tenuta meccanica sup.
37 - Seeger
38 - Tenuta meccanica inf.
39 - Girante
40 - Rondella bloccaggio girante
41 - Vite
42 - O-ring
1 - Feeding cable x2
2 - Cable press x2
3 - Cable gland x2
4 - Cable clamp x2
5 - Cable Thermal Protection
6 - Cable press
7 - Cable gland
8 - Cable clamp
9 - Handle
10 - Screw
11 - Screw
12 - Casing cover
13 - O-Ring
14 - Upper bearing support
15 - O-ring
16 - Stator with winding
17 - Motor case
18 - Screw
19 - O-ring
20 - Screw
21 - Lower bearing cover
22 - Lower bearing support
23 - Screw
24 - Oil plug
25 - O-ring
26 - Screw
27 - Seal casing cover
28 - O-ring
29 - Pump body
30 - Upper bearing
31 - Shaft with rotor
32 - Key
33 - Spring ring MIM
34 - Lower bearing
35 - Seeger
36 - Upper mechanical seal
37 - Seeger
38 - Lower mechanical seal
39 - Impeller
40 - Washer fixing
41 - Screw
42 - O-ring
41
1 - Cable èlectrique x2
2 - Prèsse-cable x2
3 - Passe-cable x2
4 - Bague de blocage de cable x2
5 - Cable pour thermosondes
6 - Prèsse-cable
7 - Passe-cable
8 - Bague de blocage de cable
9 - Pognée
10 - Vis
11 - Vis
12 - Couvercle du moteur
13 - Joint OR
14 - Support roulement sup.
15 - Joint OR
16 - Stator avec bobinage
17 - Carcasse du moteur
18 - Vis
19 - Joint OR
20 - Vis
21 - Couvercle roulement inf.
22 - Support roulement inf
23 - Vis
24 - Bouchon d'huile
25 - Joint OR
26 - Vis
27 - Couvercle garniture mècan.
28 - Joint OR
29 - Corps de pompe
30 - Roulement sup.
31 - Arbre avec rotor
32 - Clavette
33 - Anneau d'arrète MIM
34 - Roulement inf.
35 - Anneau d'arrète
36 - Garniture mécanique sup.
37 - Anneau d'arrète
38 - Garniture mécanique inf.
39 - Turbine
40 - Rondelle de fixage
41 - Vis
42 - Joint OR
