Additional Information
Troubleshooting
When the drive detects a fault it will display an error code. To locate and solve all error codes, a 'Diagnostic Tool
(App)' is available on Microsoft, Android and iOS platform via the 'Apps' store on Smartphone / Tablet, search for
'Control Techniques diagnostics tool in the Apps store'. Alternatively, please download the 'Diagnostic Tool
(App)' from the Control Techniques 'App Center' or view the diagnostics section in the Control User Guide
available for download from the Control Techniques or Leroy Somer website.

Status Indicators

The table below shows the different status indicators available on the display.
Table 10-1 Status indications
String
The drive is inhibited and cannot be run. The Drive Enable signal is not

applied to the drive enable terminal or is set to 0.
The drive is ready to run. The drive enable is active, but the drive inverter is

not active because the final drive run is not active

The drive is stopped / holding zero speed.

Supply loss condition has been detected

The drive is applying dc injection braking
The drive has tripped and no longer controlling the motor. The trip code

appears on the display.

The drive is in the under voltage state.
Restoring drive defaults
The drive can be restored to the original factory settings by following the procedure below:
1.
Ensure the drive is not enabled, i.e. terminal 11(or terminal 31 and 34 on Commander C300) is open.
2.
Select 'Def.50 (50 Hz settings) or Def.60 (60 Hz settings)' in Pr 00.
3.
Press the red
Basic parameters range and default
For information on parameters beyond Pr 00 to Pr 10 refer to the Quick Start Guide.
Parameter
01
Minimum Speed
02
Maximum Speed
03
Acceleration Rate 1
04
Deceleration Rate 1
05
Drive Configuration
06
Motor Rated Current
07
Motor Rated Speed
08
Motor Rated Voltage
09
Motor Rated Power Factor
10
User Security Status
C200/C300 Step By Step Guide
Issue Number: 1
Description
reset button.
0.00 to Pr 02 Hz
0.00 to 550.00 Hz
AV (0), AI (1), AV.Pr (2), AI.Pr (3),
PrESEt (4), PAd (5), PAd.rEF (6), E.Pot (7),
torquE (8), Pid (9)
Refer to the Control User Guide for further
0.00 to Drive Rating Amps
0.0 to 33000.0 rpm
0 to 240 V or 0 to 480 V
Refer to the Control User Guide for further
Range ()
0.0 to 32000.0 s
0.0 to 32000.0 s
information
0.00 to 1.00
information
Drive output stage
Disabled
Disabled
Enabled
Enabled
Enabled
Disabled
Disabled
Default ()
0.00 Hz
Def.50: 50.00 Hz
Def.60: 60.00 Hz
5.0 s
10.0 s
AV (0)
Maximum Heavy Duty
Rating Amps
Def.50: 1500.0 rpm
Def.60: 1800.0 rpm
110V drive: 230 V
200V drive: 230 V
400V drive Def.50: 400 V
400V drive Def.60: 460 V
0.85
LEVEL.1
