English
Please ensure that you read any specific references in this user
guide that apply to your product type. Use the following list to
identify your product type:
•
Bilevel – VPAP™ ST-A devices
•
Adaptive Servo Ventilator (ASV) – AutoSet CS™ devices.
This manual is specific to your device. Do not use with other
devices. Information for clinicians is available in the clinical guide.
Indications for Use
Your device is intended for home and hospital use.
Bilevel
Your bilevel ventilator device is intended to provide noninvasive
ventilation for patients with respiratory insufficiency or obstructive
sleep apnoea (OSA).
Adaptive Servo Ventilator (ASV)
Your adaptive servo ventilator device is intended to stabilise the
ventilation of adult patients exhibiting Cheyne-Stokes Respiration
(CSR), or central sleep apnoea (CSA) associated with congestive
heart failure, with or without upper airway obstruction. It is also
intended for the treatment of patients with obstructive sleep
apnoea (OSA).
Contraindications
Positive airway pressure may be contraindicated in some patients
with the following conditions:
•
pneumothorax or pneumomediastinum
•
pathologically low blood pressure, particularly if associated
with intravascular volume depletion
•
cerebrospinal fluid leak, recent cranial surgery or trauma
•
severe bullous lung disease
•
dehydration.
Adverse Effects
You should report unusual chest pain, severe headache or
increased breathlessness to your prescribing physician. An
acute upper respiratory tract infection may require temporary
discontinuation of treatment.
The following side effects may arise during the course of therapy
with the device:
•
drying of the nose, mouth or throat
•
bloating
•
ear or sinus discomfort
•
eye irritation
•
skin rashes
•
nosebleed.
Masks and Humidifiers
Recommended masks and humidifiers are available from your
place of purchase. For information on using your mask or
humidifier, refer to the user guide supplied with your mask or
humidifier.
Setting up your Device
Refer to illustration A on page 1.
1.
There are two sockets at the rear of your device. Insert the
power cord into the top socket and push the locking clip (a)
down to hold the cord in place.
2.
Plug the other end into a power outlet.
3.
Connect the air tubing to the air outlet of the device.
ASV only: To attach the pressure sensor tube (b) to the device,
screw the Luer connector (c) onto the socket (d) on the side
of the device. Ensure all components have been correctly
assembled and check for any split or damaged parts.
ASV air tubing is assembled as follows (refer to illustration B
on page 1):
(1) Proximal cuff; (2) Air tubing; (3) Pressure sensor tube;
(4) Tube clip; (5) Luer connector.
2.
Connect the assembled mask system to the free end of the
air tubing.
ASV only: Attach the mask to the end of the air tubing with
the proximal cuff (e).
WARNING
•
Make sure the power cord and plug are in good condition
and the equipment is not damaged.
•
Only ResMed air tubing should be used with the device.
A different type of air tubing may alter the pressure you
actually receive and reduce the effectiveness of your
treatment.
•
Blocking the tubing and/or air inlet of the device while in
operation could lead to overheating of the device.
•
Use care when handling the air tubing. Be particularly
careful when attaching the Luer connector to the device. If
you kink or excessively twist the sensor tube, it may affect
the protection offered by the mask pressure alarm system.
CAUTION
•
Be careful to place the device where it cannot be bumped,
and where no one will trip over the power cord.
•
If you put the device on the floor, make sure the area is free
from dust and clear of bedding, clothes or other objects
that could block the air inlet.
•
Make sure the area around the device is dry and clean. Take
care when using liquids around the device.
Device Control Panel
Refer to the control panel (illustrations C and D on page 1) that
best matches your device.
Your control panel may have the following items: (1) Start/Stop;
(2) LCD screen; (3) Up and Down keys; (4) Enter key; (5) Exit
key; (6) Left key; (7) Right key; (8) Alarm Mute; (9) LEDs;
(10) QuickView.
Starting Treatment
1.
Turn the main power switch at the back of the unit to on (
2.
Lie down and arrange the air tubing so that it is free to move if
you turn in your sleep.
ASV only: Select your mask type and run Learn Circuit.
3.
To start treatment, press
your device, breathing into your mask should start therapy
automatically.)
4.
Fit your mask as described in the mask user instructions.
WARNING
A mask should not be used unless the device is turned on
and operating properly.
CAUTION
Do not leave long lengths of air tubing around the top of your
bed. They could twist around your head or neck while you are
sleeping.
Stopping Treatment
To stop treatment at any time, remove your mask and press
if your device has SmartStart/Stop enabled, simply remove your
mask and treatment will end.
Using the Menus
Key Functions
Up and Down keys: Scrolls through menus and setting options.
Enter key: Enters menus; changes options; applies settings.
Exit key: Exits menu or setting.
Left key: Enters menus; changes options; applies settings.
Right key: Exits menu; cancels operation.
Menu Settings
Some menu items may not be available on your model.
Ramp: Period during which the device increases from a low
pressure to the prescribed treatment pressure.
Learn Circuit: Allows the device to 'learn' what pressure it needs
to build in to its calculations, based on the components in the
system. Select every time you add or remove a component.
2
. (If SmartStart™/Stop is enabled on
I).
or,
