Menu structure
1. Brake type
- *Brake off
- Soft Brake
- Mid Brake
- Hard Brake
2. Battery type
- NiCd / NiMH
- *LiPo
- LiFe
3. Voltage prot
- 2.8 V / 50% (with LiPo 2.8 V per cell / NiCd, NiMH 50%
of the connection voltage)
- *3.0 V / 60% (with LiPo 3.0 V per cell / NiCd, NiMH 60%
of the connection voltage)
- 3.2 V / 65% (with LiPo 3.2 V per cell / NiCd, NiMH 65%
of the connection voltage)
- No Protection
4. Motor timing
- *Auto
- 2deg / 2°
- 8deg / 8°
- 15deg / 15°
- 22deg / 22°
- 30deg / 30°
5. SBEC output
- *5.0 V
- 6.0 V
- 7.4 V (with PROcontrol 45 only 5.0 V)
- 8.4 V (with PROcontrol 45 only 5.0 V)
6. Governor mode
- *RPM OFF
- 1st soft / soft start with 8-second delay
- 2nd soft / soft start with 15-second delay
- 1st Governor / Governor mode 1 (motors with low KV)
- 2nd Governor / Governor mode 2 (motors with high KV)
7. Motor rotation
- *Forward
- Reverse
8.Start strength
- 10%
- 15%
- 20%
- 25%
- *30%
- 35%
- 40%
- 45%
- 50%
9. Cut off type
- *Reduce power
- Cut off power
The parameters marked with * are factory settings. A comprehen-
sive description of the individual parameters can be found in the
operating instructions of the PROcontrol controllers.
ROXXY PROcontrol Series – Operating instructions
GUARANTEE / LIABILITY EXCLUSION
Our products are covered by the currently valid statutory guarantee
regulations. If you wish to make a claim under guarantee, please
contact the model shop where you originally purchased the unit.
The guarantee does not cover faults caused by:
- Incorrect handling, incorrect connections, reversed polarity
- The use of accessories other than original MULTIPLEX items
- Modifications or repairs not carried out by MULTIPLEX or by an
authorised MULTIPLEX Service Centre
- Accidental or deliberate damage
- Normal wear and tear
- Use of the unit outside the stated Specification
MULTIPLEX Modellsport GmbH & Co.KG accepts no liability for loss,
damage or costs which are caused by the incorrect or incompetent
use of the product, or are con-nected with such use in any way.
CE CONFORMITY DECLARATION
This device has been assessed in accordance with
the relevant harmonised European directives. You are
therefore the owner of a product whose design fulfils
the protective aims of the European Community relating
to the safe operation of equipment. You are entitled to see the
conformity declaration.
Please ask MULTIPLEX Modellsport GmbH & Co.KG for a copy.
DISPOSAL NOTES
equipment must not be discarded via the normal domestic refuse
system (WEEE - Waste of Electrical and Electronic Equipment,
Directive 2002/96/EG). You can take un-wanted equipment to your
nearest local authority waste collection point or recycling centre,
where the staff will dispose of it correctly and at no cost to yourself.
By returning your unwanted equipment you can make an important
contribution to the protection of our shared environment!
4
EElectrical equipment marked with the cancelled waste
bin symbol must not be discarded in the standard
household waste; instead it must be taken to a suitable
specialist disposal or recycling system.
In the countries of the EU (European Union), electrical
