Spa Set-Up - mspa Alpine B-091 Manuel De L'utilisateur

SPA SET-UP

1. Move the entire package to the selected site. Open the carton carefully as it can be used to store the spa during long term storage
or when not in use.
2. Lay out all the parts on the ground and make sure all parts are accounted for. Make sure the spa tube is right side up. (*For
missing or damaged part, contact the MSpa Service Center)
3. Spread the Heat Preservation Ground Mat over a cleared area. Spread out the spa liner over the ground mat. Heat Preservation
Mat prevents heat loss from the bottom of the unit.
NOTE: The heat preservation ground mat is not included for the MSpa LITE package . We suggest to find a ground mat and put it
between the ground and spa tub to help prevent scratch and heat loss.
1
NOTE:
Nest B-100: For this model, a side bar is included in the package. Set
up the wicker bar and place the supporting legs underneath the spa tub
before filling the water. It helps keeping the oval spa in a proper shape
after water filling and inflation.
Alpine B-090/091: Spread out the
square ground mat and place it to
the selected site. Make sure the
buckle of cover and mat is attached
when spa not in use.
4. Connect the digital cable. Find the
digital cable as well as the digital cable
gard cover and self-tapping screw.
Get the digital cable through the gard cover, loose the cap on the end, and plug into the cable port on the control panel. Once the
cable is connected properly, power is ON, a yellow signal will light up beside the ON/OFF button on the panel. Then secure the
gard cover onto control panel by using a Phillips screw driver to tighten the self-tapping screw down to the hole in digital cable
gard cover accordingly. Drill slowly until the screw stops and complete the assembly. Do not diassemble the gard cover
including storage purpose!
4
2
11
3
this side
face down
