EN
•
•
•
50
#8 M8*20 6PCS
26
29
58
8
60
58
56
9
9
56
8
61
Attach the bottle holder (92) to the support tube (26).
Connect the tension wire (59) to the tension control knob (30). Connect the sensor
wire (60) to the middle wire (29).
Attach the support tube (26) to the main frame (61), tighten it and secure it with
bolt (8), washer (56), arc washer (9) and spring washer (9). Then attach the bottle
(93) to the bottle holder (92).
3
#56 d8*Φ20*1.5 4PCS
#58 d8*Φ20*1.5*R30 2PCS
92
93
8
#9 M8 6PCS
S6
