Operating Instructions SATA spray master RP
EN
■ Insert trigger guard.
■ Insert guard bolt.
■ Insert circlips.
■ Insert paint needle and spring.
■ Screw adjusting screw [1-4] with counter nut into gun body.
9.2. Replace nozzle set
Damage from incorrect installation
The fluid tip and paint needle can be damaged if assembled in the
wrong order.
→ Always comply with the assembly sequence. Never screw the fluid tip
against an energised paint needle.
The nozzle set consists of a tested combination of air cap, fluid tip and
paint needle. Always replace the complete nozzle set.
Dismantle the nozzle set
■ Loosen counter nut of adjusting screw [1-4].
■ Screw adjusting screw with counter nut out of gun body.
■ Remove spring and paint needle.
■ Unscrew air cap [1-13].
■ Screw fluid tip out of gun body using universal spanner.
Mount the nozzle set
■ Screw fluid tip into gun body using universal spanner and tighten with a
torque of 14 Nm.
■ Screw air cap [1-13] onto gun body.
■ Insert paint needle and spring.
■ Screw adjusting screw [1-4] with counter nut into gun body.
After installation, adjust the material flow according to chapter 8.2.
9.3. Replace paint needle seal
This must be replaced when material leaks from the self-adjusting paint
needle packing.
Dismantle paint needle seal
■ Loosen counter nut.
■ Screw adjusting screw [1-4] with counter nut out of gun body.
■ Remove spring and paint needle.
■ Remove trigger guard [1-12] (see chapter 9.1).
■ Screw paint needle seal [# 6445] out of gun body using socket span-
120
