SOMFY S&SO-RS100 io HYBRID Notice page 55

For a roller shutter
with rigid links and
with stops = Plug&Play
Operation
No setting to be performed:
the end limits are
automatically.
Check that the roller
shutter and its accessories
are robustly fixed.
Please consult the roller
shutter manufacturer or
Somfy for information on
the compatibility of the
drive with the roller shutter
and its accessories.
Step A2 (optional): Programming a io-homecontrol
Copyright © 2014 - 2016 Somfy SAS. All rights reserved.
Procedure
For a roller shutter
without rigid links and
without stops
The upper and lower end limits
set must be set in manual mode.
Step A1
Setting / resetting of
end limits in manual
OPERATION with the wired control point
OPERATION with a io-homecontrol
diagram A
a
:
mode
control point
®
For a roller shutter
without rigid links and
with stops or with rigid
links and without stops
The upper and lower end limits
must be set in semi-automatic
mode.
b
Step A1 :
Setting / resetting of
end limits in semi-
automatic mode
control point
®
Non contractual images.
