POWER SUPPLY HARDWARE

The Notebook can be
operated by battery or by
power supply.
The initial use will be
by power supply, as the
battery is ony partially
loaded for shipping.
Only use the original
power supply. A wrong
power supply can damage
your notebook.
WARNING
The Power Supply
contains no servicable
parts
DANGER!!
UNDER NO
CIRCUMSTANCE
OPEN THE POWER
SUPPLY!
DANGER!!
WARNING
The notebook comes with an AC power cord and a uni-
versal, autoswitching power adapter.
You can use the adapter anywhere the voltage is steady,
between 100 and 240 volts.
When the adapter is connected to a power source and
then to the computer, the Power icon lights up to
indicate the system is receiving AC power.
To use the AC adapter: :
1. Plug the power cord to the power adapter.
2. Plug the power adapter to the DC IN 19V socket on
the computer´s rear panel.
3. Plug the power cord into a wall outlet.
Figure 6
THE PREPARATION
47
