INTRODUCTION

Rear View

À
Figure 10
(1) Parallel port
(2) Infrared port
(3) Vent
(4) Security lock
(5) Dual USB ports *
(6) S-Video Connector
(7) External Monitor (CRT) Port
(8) PS/2 type port (ext. Mouse or Keyboard)
(9) LAN jack/Phone jacks
(10) AC-in jack
Bottom View
À
Ã
Figure 10
52
Ä
Á
 Å
Ã
Á
Â
Ä
Å
 Æ
Ç
(1) CPU cover
(2) Fan outlet *
(3) CD-ROM or DVD-ROM Drive
release latch
(4) Cover for HDD (Hard Disk
Drive)
(5) Battery release latches
Ä
(6) Battery
*Overheating
To prevent your computer from overheating
make sure nothing blocks the vent while the
computer is in use.
É
È
* Windows NT 4 doesn´t
support USB
