1.3 Configurations

The hydraulic cylinder for outboard engine UC95-OBF model can be installed on boats equipped with single or
dual engine and with single or dual steering station.
The maximum power of the single engine or the total (combined) maximum power of the two engines must not
exceed 175 hp.
STEERING STATION NUMBER
S
I
N
G
L
E
S
T
A
T
I
O
N
D
U
MAIN STATION
A
L
ADDITIONAL
S
STATION
T
A
T
I
O
N
CAUTION
Also in case of single engine applications with a horsepower which exceeds 175hp or 55 m.p.h., it is necessary
to assemble the ULTRAFLEX UC 128-OBF or UC128-SVS cylinder.
page 8
of 79 -
HYDRAULIC CYLINDER FOR OUTBOARD ENGINE
S
I
N
G
L
E
E
N
G
I
N
E
With SINGLE CYLINDER
D
U
A
L
E
N
G
I
N
E
With SINGLE CYLINDER
Check the compatibility of the tie bar with the engines
Installation and Maintenance Manual
ENGINE NUMBER
up to 175hp max
or 55 m.p.h.
up to 175hp max
total
or 55 m.p.h.
and TIE BAR TYPE A92
