Replacing the EMF2172IB communication module (CAN)
Activate the 2. SDO channel
Depending on the standard device used, set code C1865/1 or C2365/1 to activate the 2. SDO
channel.
Settings via the GDC/XT keypad for these standard devices:
EVS 93xx−ES
EVS 93xx−EP
EVS 93xx−EK
EVS 93xx−ER
EVF 93xx−EV
E82EVxxx
1. Plug the EMF2178IB communication module
onto the standard device.
2. Use the GDC to set code C1865/1 = 1.
The setting is saved with mains failure
protection directly in the communication
module.
When using the standard devices specified
above, the setting can also be carried out
beforehand.
EDKMF2178IB DE/EN/FR 6.1
EVS 93xx−EI
EVS 93xx−ET
EPL−10200
ECSxS/P/M/A
Use the GDC or XT keypad to set standard device
code C2365/1 = 1 and save it with mains failure
protection.
After mains connection of one of the standard
devices specified above, or after plugging on the
EMF2178IB communication module, the contents
of C2365 are written to the communication
module.
