English
• BALANCE: Changes left/right balance. (For more information on Balance
sections.)
NOTE: This setting is stored permanently even after the RC-1590 is
powered off.
• DIMMER: Dims the display.
NOTE: This setting is stored permanently even after the RC-1590 is
powered off.
• ROTEL LINK RCD: Selects how the CD player is connected to the amplifier,
either CD (analog), COAX1, COAX2 and BAL-XLR. CD is the factory default.
• POWER ON MAX VOLUME: This sets the maximum volume level when
the unit is turned ON. "45" is the factory default.
NOTE: Power On Max Volume settings do not apply to sources
configured with Fixed Gain.
• POWER OPTION: Enables the RC-1590 to be controlled via the network
port when attached to an automation system. The power consumption is
higher in Quick Power mode. If network control is not required select the
Normal Power mode. "Normal" is the factory default.
• AUTO POWER OFF: The RC-1590 can be configured to automatically
power off if unused for a specified period. If no changes are made to the
unit within the specified "Auto Power Off" timer the unit will automatically
go to STANDBY mode. The Auto Power Off timer will be restarted if changes
are made to the volume, source or playback. The default for Auto Power
Off is set to DISABLE.
Valid settings include: DISABLE, 1 HOUR, 2 HOURS, 5 HOURS, 12 HOURS.
• FIXED GAIN: Configures a Fixed Volume level for a specified input. To
enable this feature press the +/- buttons on the front panel to select the
desired fixed volume level for Aux, FUSB, PC-USB, Coax 1, Coax 2, Optical
1, Optical 2 or Bluetooth. When enabled and the input with a Fixed Volume
is selected, the Volume level will immediately be set to the specified level.
Valid settings include: VARIABLE, FIXED 01-95, FIXED MAX.
• AUX VOL: VARIABLE (disabled) is factory default.
• FUSB VOL: VARIABLE (disabled) is factory default.
• PC-USB VOL: VARIABLE (disabled) is factory default.
• OPT1 VOL: VARIABLE (disabled) is factory default.
• OPT2 VOL: VARIABLE (disabled) is factory default.
• COAX1 VOL: VARIABLE (disabled) is factory default.
• COAX2 VOL: VARIABLE (disabled) is factory default.
• BLUETOOTH VOL: VARIABLE (disabled) is factory default.
NOTE: The Volume knob on the front panel and Volume +/- buttons
on the IR remote are disabled when the volume is Fixed. To disable this
feature set the Fixed Volume level to "Variable".
• PC-USB AUDIO CLASS: Changes supported PC-USB Audio Class of the
attached device.
NOTE: Some computers attached to the PC-USB do not support USB
Audio Class 2.0 and do not support 24/192 audio playback. If needed
the PC-USB can be configured for USB Audio Class 1.0. Please consult
your computer operating system for details.
• NETWORK: Shows the network connection status and to view/configure
the network settings. If the network is properly configured and attached
"Connected" will be displayed. To view or modify the network settings
press the ENTER button.
The RC-1590 supports both DHCP and STATIC IP addressing. Select the
desired IP address method and press ENTER.
If DHCP is selected you can refresh IP address by pressing ENTER or press
MENU to view IP address information. Press the MENU button to toggle
through IP address settings. If the IP address is renewed the network will
be tested and connection status reported.
If STATIC IP address mode is selected you must configure all settings for the
network including IP Address, Subnet Mask, Gateway and DNS Server. Use
the left/right or +/- buttons to adjust the values and press ENTER to move to
the next value. When the proper IP information is configured press MENU
to go to the next setting. After entering the STATIC IP address information
the network will be tested and connection status reported.
NOTE: For more information regarding network connection please
contact your authorized Rotel dealer.
NOTE: A network connection is not required for the RC-1590 to
operate.
• MAIN: This shows the current software version loaded into the RC-1590.
The software can be updated if the RC-1590 is properly connected to the
Internet.
• Press ENTER to check if a new software version is available.
• If a new software version is available press the + button on the front
panel or the right button on the remote control to select YES then press
ENTER button to begin the software update process.
• The new software will be downloaded from the Internet. The RC-1590
will power cycle when the software update is complete.
NOTE: Do NOT power off the RC-1590 during the software update
process.
NOTE: It is recommended to Reset Factory Defaults after the software
update is complete.
• PC-USB: This shows current loaded software version for PC-USB processor.
• FACTORY DEFAULT: This sets the unit back to the original state as when
it left the factory. Press the + button on the front panel or the Right button
on the remote control to select <YES> then press the ENTER button on the
front panel or on the remote control.
