System Settings

The RDX2 Pro will be operated with the default value for the essential user settings when it is powered on for
the first time. The screen displays the following information in sequence and the user can change the param-
eter value of each screen. To change a parameter value in the system program, press START/ENTER to make
it blink then change the value with the dial button. The value will be stored by pressing START/ENTER once.
ITEM
POWER SET
A
U=0.0V I=0.0A
SAFETY TIMER
A
ON
CAPACITY CUT-OFF
A
ON
TEMPERATURE UNIT
A
A
CHG > DCHG 10 Min
28
SELECTION
U: 5.0-25.0V
I: 0.1-14.0A
OFF/ON
(1-720 Min)
120 MIN
OFF/ON
(100-50000 mAh)
5000mAh
Celsius
Fahrenheit
CELSIUS
1-60 Min
REST TIME
DESCRIPTION
130W rated power for both Channel A and
Channel B. Power supply function is available
under AC/DC mode.
When you start a charge process, the integral
safety timer automatically starts running at the
same time. This is programmed to prevent over-
charge the battery if it proves to be faulty, or if the
termination circuit cannot detect the battery full.
The value for the safety timer should be generous
enough to allow a full charge of the battery.
This program sets the maximum charge capacity
that will be supplied to the battery during charge.
If the delta peak voltage is not detected nor the
safety timer expired for any reason, this feature
will automatically stop the process at the selected
capacity value.
You can choose the temperature displayed by
Celsius or Fahrenheit as you like.
A rest time allowing the battery to cool down
between charging/discharging cycle.
