Features
Re-Peak Mode of NiMH/NiCd Batteries:
In Re-Peak charge mode, the charger can peak charge the battery once, twice, or three times in a
row automatically. This function is useful for ensuring a full battery charge.
Cyclic Charging / Discharging:
A battery can be cycled 1 to 5 times consecutively. This process is normally used for NiCd or NiMH
packs that have lost capacity over time. It is not recommended for Lithium packs.
NiMH / NiCd Auto Charging:
Charging current is determined by the charger up to the maximum set by the user by evaluating the
internal resistance of the pack so as not to charge at too high of a rate. This mode is recommended
when charging NiMH or NiCd batteries where you are unsure of the optimal rate at which to charge.
Delta-Peak Sensitivity for NiMH/NiCd:
This function determines the amount of voltage drop in MV that must be achieved for the Delta-Peak
algorithm to automatically terminate the charge process. This can be raised for packs that have a
tendency to "False Peak" at the default setting.

Battery Meter:

The user can check not only the MAIN pack voltage, but the highest and lowest voltage is also stored,
as well as each individual cell.
Battery Resistance:
The user can also check the battery's total internal resistance and the internal resistance of each cell.
This is helpful when determining the health of a pack.
Capacity Cut-Off Limit:
This feature allows the user to set a limit for the maximum mAh's that can be put into the pack. Once
this limit is reached, the charge process will automatically terminate, and "OVER CHARGE CAPACITY
LIMIT" will be displayed. Default is 5000mAh, so set this accordingly to the rated capacity of the
pack. To ensure the pack gets fully charged, this setting should be at least 10% higher than the rated
capacity on the pack or turned to off.
Safety Timer:
Protect your battery by setting a maximum time limit for charging. Once this limit is reached, the
charge process will automatically terminate, and "OVER TIME LIMIT" will be displayed. Default is 120
minutes, so adjust as needed depending on the charge rate and capacity of the pack.
USB Power 5V/2.1A:
You can charge your phone, tablet or any other USB-powered devices using the built-in USB port.
Battery Charge Percentage:
The battery charge percentage is displayed in real time once you are charging. To view, SCROLL to the
left with the Jog Dial to monitor.
Power Supply:
With the built in Power Supply function, you can power devices with up to 25V @130W.
NOTE: IF THE POWER SUPPLY FUNCTION IS ACTIVATED, CHARGING IS DISABLED.
