Cooktop Use - KENMORE ELITE 664.7522 Série Guide D'utilisation Et D'entretien

Keypad Feature
WARMING Slow cook drawer 1. Press WARMING DRAWER SLOW COOK to select the Slow Cook function at the
DRAWER SLOW
COOK/OFF
DELAY START Delayed start
COOK TIME Timed cooking
LO TEMP CLEAN Clean cycle
START (hold Oven control
3 sec) lockout
WARNING
Do not let the burner flame extend beyond the edge of
the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can result in death
or fire.
Electric igniters automatically light the surface burners
when control knobs are turned to Lite.
Before setting a control knob, place filled cookware on
the grate. Do not operate a burner using empty cookware
or without cookware on the grate.
10
Instructions
Low setting.
2. To select a higher temperature setting, press WARMING DRAWER SLOW COOK
a second time for the High setting.
3. Place the food(s) in the warming drawer.
4. Press START to begin heating the warming drawer.
5. Press WARMING DRAWER OFF to turn off the heating element.
Refer to the "Warming Drawer" section for more information.
The Delay Start keypad is used to enter the starting time for an oven function with
a delayed start. Delay Start should not be used for foods such as breads and cakes
because they may not bake properly.
To set a Timed Cook or a Delayed Timed Cook, see the "Cook Time" section.
Cook Time allows the oven to be set to turn on at a certain time of day, cook for a set
length of time, and/or shut off automatically.
To set a Timed Cook or a Delayed Timed Cook, see the "Cook Time" section.
See the "Clean Cycle" section.
1. Check that the oven is off.
2. Press and hold START (hold 3 sec) for 3 seconds.
3. A tone will sound and "Control Locked" will scroll, and then "Locked" will be
displayed.
4. Repeat to unlock. No keypads will function with the controls locked. The cooktop
functions are not affected by the oven control lockout.

COOKTOP USE

Fire Hazard
To Set:
1. Push in and turn knob counterclockwise to LITE.
All surface burners will click. Only the burner with the
control knob turned to Lite will produce a flame.
2. Turn knob to anywhere between Hi and Lo.
REMEMBER: When range is in use, the entire cooktop area
may become hot.
Power Failure
In case of prolonged power failure, the surface burners can
be lit manually. Hold a lit match near a burner, and then turn
knob counterclockwise to LITE. After the burner lights, turn
knob to setting.
