Installation Procedure
Installation
Led Indicator:
Tab. 2
Pos Led: 1 Blink every
2 sec
Neg Led: 1 Blink
every 2 sec
Pos Led:
2 Blink every 2 sec
Neg Led:
2 Blink every 2 sec
Pos Led:
3 Blink every 2 sec
Neg Led:
3 Blink every 2 sec
Led Pos:
4 Blink every 2 sec
Led Neg:
4 Blink every 2 sec
1 Blink of both LED
every 2 sec
No Blink of both LED
28/42
HV POS ON: Normal Operation
HV NEG ON: Normal Operation
HV POS Short Circuit: Output Voltage < 100 V and Output
Current
> 4 mA for more of 1 minute
HV NEG Short Circuit: Output Voltage < 100 V and Output
Current
> 4 mA for more of 1 minute
HV POS Out of Order: The value of Output Voltage is major of
120 % or minor of 80 % of the Target Value, for more of
1 minute
HV NEG Out of Order: The value of Output Voltage is major of
120 % or minor of 80 % of the Target Value, for more of
1 minute
Interlock cable not connected
Interlock cable not connected
The supply voltage is under 19 Vdc for more of 1 minute.
HV OFF: The supply voltage is under 15 Vdc for more of
2 minutes
Ion Pumps Controller 24 V User Manual / 87-900-127-01 (C)
