ATTACH VENTING: OPTION 2 - NON DUCTED
RECIRCULATING
For Non-Ducted Recirculation venting
1
route the ductwork to a location above
the hood where the discharge is vented
back into the room.
Use the included Recirculation Vent Grill
to cover the opening. Secure the grill
D
with the 2 screws
Install Kit.
A straight 6" round duct that is at least
15" in length should be used to lead air
from the top of the hood exhaust outlet
to the exit of the cabinet above.
Required Activated Charcoal Filter
Accessory - sku # - FILTER1
Long Lasting Activated Charcoal Filter
Accessory - sku # FILTER1LL
(purchased separately)
18
provided in the
G
D
G
