Aquatec® R / F / XL

5.3 Bathing

WARNING!
Risk of Slipping
The bath lift can slip if the suction cups do not
have a proper hold.
– Before using the bath lift ensure that it is
securely positioned and cannot tip over.
– Ensure that the bath lift is set up in a bathtub
with the correct dimensions, refer to 4.2
Setting up Bath Lift, page 11.
WARNING!
Risk of Injury
– If your condition means that you cannot take
a bath on your own, only use the device with
supervision.
– If operating the device without supervision,
make sure to have an alarm system or
telephone within reach in case of unforeseen
events (e.g. malfunctions).
– Before using, check the temperature of the
bath water.
Risk of Damage
Bath oils or salts can impair the performance of
the lifting scissors.
– If using such bath additives, do not exceed the
recommended dose.
Run the unloaded lift once to the top and then back
to the bottom (function test).
18
1. Press and hold the Up button until the seat is level with
the edge of the bathtub.
2. Make sure that the side flaps are level with the seat and
rest flat on the edge of the bathtub (initial position).
3. Fill the bathtub with water.
4. Sit on the side flap nearest to you as you would on a
chair.
5. Slide backwards until you are sitting in the middle of
the seat.
6. Turn yourself into the bathing position, by lifting one leg
and then the other over the edge of the bathtub.
7. Once you are sitting correctly, press and hold the Down
button to lower the seat into the bathtub.
Once the seat has reached the lowest position, it is
possible to recline the backrest by continuing to hold
the Down button. This produces a more comfortable
bathing position and allows you to immerse yourself
deeper in the bath water (not on model F).
8. Keep the Down button pressed until the backrest has
reached the desired position.
To get out of the bathtub, follow these steps in
reverse order.
9. To raise the backrest or the bath lift, press and hold
the Up button until the seat is at the same level with
the bathtub edge.
Risk of Damage
– Disconnect the hand control from the device
when the bath lift is not in use, refer to 6.2
Removing Bath Lift, page 19, step 3.
