Rotel products are designed to comply with international directives on the Restriction
of Hazardous Substances (RoHS) in electrical and electronic equipment and the
disposal of Waste Electrical and Electronic Equipment (WEEE). The crossed wheelie
bin symbol indicates compliance and that the products must be appropriately
recycled or processed in accordance with these directives.
This symbol means that this unit is double insulated. An earth connection is not
required.
Pin Assignments
Balanced Audio (3 pole XLR):
Pin 1: Ground / Screen
1 2
Pin 2: In phase / +ve / Hot
3
Pin 3: Out of phase / -ve / Cold
RCD-1572 Stereo Compact Disc Player
RCD-1572
POWER
REPEAT RANDOM TIME
IMPORTANT FOR LASER PRODUCTS
CLASS 1
LASER PRODUCT
1. CLASS 1 LASER PRODUCT
APPAREIL LASER
DE CLASSE 1
2. DANGER: Visible laser radiation when open and interlock failed
or bypassed. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the player; leave all servicing to qualified
service personnel.
WARNING!
To reduce the risk of electrical shock, fires, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose the unit to rain or moisture.
3. Do not touch the power cord or plug with wet hands.
