Terrazza Pure | 127592-0000 w | v14 | 2021-11-08 | Montageanleitung | Montagehandleiding | Instructions for assembly | Instructions de montage
1
Erdung wieder anklemmen
(Option RGB / E-Anschlüsse)
Aarding weer aanklemmen
(optie RGB / e-aansluitingen)
Reconnecting the earthing
(RGB / electrical connections option)
Rebrancher la mise à la terre
(option RGB / raccords électriques)
Elektrische Leitungen durch vorgesehene Kabeldurchführungen ziehen, um eine Beschädung der Kabel abzuwenden!
worden afgeklemd! Trek elektrische kabels bij de montage van de frameprofielen door de hiervoor aangebrachte
kabeldoorvoeren! Zo voorkomt u dat de kabels beschadigd raken!
bushing when installing the frame profile to prevent any damage to the lead!
passe-câbles prévus lors du montage des profilés de cadre afin d'éviter tout endommagement des câbles!
Kabel, Stecker, Steuerungen, Netzteile, etc. sind bereits produktseitig in den jeweiligen Produktkomponenten
integriert und gekennzeichnet. Der Netzkabelanschluss erfolgt am Wandanschlussprofil im Bereich des ersten Dachfeldes
auf der Seite des Stromanschlusses. Die Steuerungen (E-Komponenten) sitzen immer im Dachfeld daneben.
ten opgenomen en gemarkeerd. De aansluiting van de voedingskabel geschiedt aan het wandaansluitingsprofiel in
het gedeelte van het eerste dakveld aan de zijde van de stroomaansluiting. De besturingen (elektrische componenten)
bevinden zich altijd in het dakveld ernaast.
The leads, plug connectors, controls, power supply packs, etc. are already integrated into the product compo-
nents and marked on the product. The power cable is connected on the wall gap sealing profile in the area of the first
roof panel on the power connection side. The controls (e-components) are always in the roof panel next to this.
les composants du produit. Le câble de réseau est branché au profilé de raccord mural dans
la zone du premier toit de panneau sur le côté du raccord électrique. Les commandes
(composants électriques) se trouvent toujours à côté dans la zone du toit !
Technische Änderungen vorbehalten | Technische wijzigingen voorbehouden | We reserve the right to make technical changes | Sous réserve de modifications techniques
Elektrische Leitungen bei der Montage der Rahmenprofile nicht quetschen!
Do not squash the electric cables! Pull the electric cables through the provided cable
N'écrasez pas les lignes électriques! Tirer les lignes électriques à travers les
kabels, stekkers, besturingen, netadapters, etc. zijn al in de fabriek in de betreffende productcomponen-
les câbles, fiches, commandes, blocs d'alimentation, etc. sont déjà intégrés et marqués sur le produit dans
RGB
Modul |
module
De elektrische kabels mogen bij de montage van de frameprofielenniet
3G0,75 mm²
3 G0,75 mm²
230 V~
230 V~
230 V~
2500 mm
3 G0,75 mm²
230 V~
39
