Roxxy
BL-Outrunner
®
®
New 14-pole ROXXY
BL D-series outrunner motor, with triple ball-
races. D-series motors feature a third bearing, known as a thin-ring
ballrace, for improved true-running and precision. This prevents the
motor bell distorting under load, and ensures smooth running. These
motors require no gearbox due to their construction. They are highly
efficient, high-torque motors with a wide power band, capable of
driving large propellers.
Typical application
For electric gliders up to about 11 kg
Scale and sport models up to about 6 kg
Aerobatic and 3-D models up to about 4 kg
Installation advice
- Select the fixing screws length so that no damage to the motor
occurs. Use (Loctite 648) thread-lock fluid so that the screws do
not loosen in use. The thread-lock fluid must not get into the ball
bearings.
- Ensure the outrunner bell runs freely.
- Do not use damaged propellers.
- Ensure that neither dirt, water nor metal particles can enter the
inner workings of the motor.
- If the motor runs in the wrong direction, swap two the three power
cables over.
Recommended LiPo batteries
ROXXY
®
Power LiPo-batteries
Specification
D50-65-10 290 Kv No. 31 4666
Voltage
Rotational speed
Load current
Max. load current
Dimensions
Weight approx.
Shaft diameter
63 mm
1mm
18 mm
www.modellmarkt24.ch
www.modellmarkt24.ch
Roxxy® BL-Outrunner – Bedienungsanleitung, Operating instructions,
Notice d'utilisation, Istruzioni per l'utilizzo –
20-36 Volt / 5-9 LiPo
290 rpm / V
50 A (5 min / 120°C)
70 A (60 secs.)
Ø 50 x 65 mm
412 g
6 mm
20 mm
6 mm
D50-65
Suitable Roxxy-BL-controllers
No.
Type
31 8634
960-6
31 8639
975-12 Opto
Prop data table No. 31 4666
Voltage
LiPo-cells
Imax (A)
Propeller
(V)
(5 min)
21,0
6
50
17 x 8 APC_E
21,0
6
50
17 x 10 APC_E
24,5
7
50
16 x 8 APC_E
24,5
7
50
17 x 8 APC_E
24,5
7
50
17 x 10 APC_E
28,0
8
50
14 x 10 APC_E
28,0
8
50
15 x 8 APC_E
28,0
8
50
16 x 8 APC_E
28,0
8
50
17 x 8 APC_E
31,5
9
50
14 x 10 APC_E
31,5
9
50
15 x 8 APC_E
!
Safety notes for operating the motor
- Whenever you are installing or otherwise handling the motor or speed control-
ler, be sure to observe the instructions supplied with those units.
- It is also important to study the instructions provided with the LiPo battery
before using them for the first time.
- Whenever you are working on the model - making adjustments, carrying out
maintenance etc. - keep well clear of the rotational plane of the propeller, as
it constitutes an injury hazard. Do not let anybody stand in front of the model
when the engine is running.
DISPOSAL
This symbol means that it is essential to dispose of electrical and elec-
tronic equipment separately from the domestic refuse when it reaches the
end of its useful life. Take your unwanted equipment to your local com-
munal collection point or recycling centre. This applies to all countries of
the European Union, and to other European countries with separate waste
collection systems.
CE CONFORMITY DECLARATION
This device has been assessed and approved in accordance with European harmonised
directives. This means that you possess a product whose design and construction fulfil
the protective aims of the European Community designed to ensure the safe operation
of equipment.
If required, you can request MULTIPLEX Modellsport GmbH & Co.KG to supply a copy
of the unit's Conformity Declaration. Please contact the company using the contact
details at the foot of the page.
Errors and omissions excepted.
Technical modifications reserved.
Copyright Multiplex Modellsport 2015
Duplication and copying of the text, in whole or in part, is only permitted with the prior written
approval of Multiplex Modellsport GmbH & Co.KG
Multiplex Modellsport GmbH & Co. KG
Westliche Gewerbestr. 1
75015 Bretten
Germany
Multiplex Service: +49 (0) 7252 - 5 80 93 33
www.multiplex-rc.de
No. 31 4666
LiPo cellcount / Load current (A)
2-6S / 60A
4-12S / 75A
Efficiency
Rpm
Load
Thrust
(%)
current (A)
(g)
87 %
5.585
24,5
3.351
87 %
5.459
30,7
3.472
87 %
6.478
28,2
3.862
87 %
6.401
31,8
4.401
86 %
6.232
39,7
4.524
89 %
7.528
28,7
2.801
89 %
7.540
28,1
3.687
88 %
7.372
35,9
5.000
88 %
7.273
40,5
5.682
89 %
8.386
36,1
3.458
89 %
8.415
34,7
4.592
