HYDRAULIKPLAN DER ABFALLBEHÄLTERHUBANLAGE
Legende
1.
Öltank
2.
Ölfi lter
3.
Pumpe
4.
Motor
5.
Absperrventil Hubzylinder
6.
Hubzylinder Abfallbehälter

HYDRAULIKPLAN DER ANTRIEBSANLAGE

Legende
1.
Öltank
2.
Ölfi lter
3.
Pumpe
4.
Motoren
1463514000(1)2008-05 A
6
5
200 BAR
110 BAR
750cc / HYDRAULIC OIL 32 cSt
1
10,2 CC/REV.
A
3000
RPM
B
2
100
MICRON
1
BETRIEBSANLEITUNG
200 BAR
3
70 BAR
4
2
4
A
88 CC/REV.
88 CC/REV.
3
A
4
FLOORTEC R 680 P
DEUTSCH
B
B
P100210
P100211
13
