1.2 RIDE+ Pro Controller
• Switching system On / Off
Push any of the two upper buttons to switch the system
'on'. Push button to switch the system off. When
switched on, the bike is in cycle mode (zero assist).
• Assistance / Regeneration Level
Push '+' button once for assistance level 1, again
for higher levels. Push '-' button to go to a lower level.
Regeneration levels can be controlled in a similar way.
Push '-' button once for regeneration level 1, again for a
higher level. Push '+' button to reduce regeneration.
Notice: It is strongly advised to ride away in a
straight line when an assistance level is selected. Never select assistance level 3 or 4 during maneuvering
or riding away in a tight corner. The powerful reaction of motor might take you unawares.
• Switching lights On / Off
Press the button for 2 seconds to switch On / Off
the Controller display light, and, if present, the front and
rear lights. Once activated, the text 'Light On' or 'Light
Off' will appear in the lower field of the display.
• See time, average speed, odometer, trip distance
Use button to change bike computer functions
(Order of appearance: trip distance, odometer, average
speed, time). To prevent loss of riding information,
please make sure that the system is switched off
before the controller is removed from the bike.
• Using the RIDE+ Link
Most bikes with the 'RIDE+ Pro' controller positioned on the middle clamp are
equipped (or can be equipped) with the RIDE+ Link. This device can be used to
select a higher or lower assist or regeneration level and to turn the lights On/Off
without removing your hands off the handlebars.The red throttle button on the
RIDE+ Link is a convenient help to move the bike without pedaling (up to 4 km/h)
walking next to the e-bike.
Caution:Beware of unintended use of the throttle button when the system is switched on.
RIDE+ Pro Controller - Quick start
