2 Description and Function
Your wall mount is made for mounting your flat screen at stable, vertical walls.
The compact and slim design supports individual, space-saving mounting. It is
tiltable but not swivelable.
2.1
Scope of Delivery
Part
Wall mounting
Wall mount
Wall screw 6.3x55
Concrete anchor
Spacer D6
Spirit level
Flat screen mounting
left Adapter bracket
right Adapter bracket
M5x14
M6x14
M6x30
Figure
Symbol
Amount
A
1
W-A
4
W-B
4
W-C
4
D
1
B
1
C
1
M-A
4
M-B
4
M-C
4
