Technical Description

6
Technical Description
The Marine Climate System marine air conditioner is designed to be
run on 230 V~.
The Marine Climate System kit contains the air conditioning unit and
these components:
Control panel
Ducting
Supply-air grille
Return-air grille
Seawater pump
Strainer
Speed scoop thru-hull
Overboard fitting
Seawater hose
Fittings for pump and strainer
The system is a seawater cooled air conditioning system.
6.1
Components of the Marine Climate System
fig. 1, page 2
14
Item in
Description
1
Duct ring
2
Rotary compressor
3
Condensate drain (one of multiple locations shown)
4
Electrical box
5
Mounting bracket
6
Base pan
7
Plugged hole (optional condensate drain location)
8
Blower assembly
9
Screws (remove to rotate blower)
10
Condenser coil (seawater outlet)
11
Evaporator coil
MCS5, MCS15
