Besides the throttle function all other control functions can be assigned differently. The different com-
binations are called Mode 1, Mode 2, Mode 3 and Mode 4. The schematics shown below explain the
different modes with the corresponding potentiometer connections as well as the settings on the DIP
switch.
Mode 1
Tail Rotor/Rudder
Mode 2
Tail Rotor/Rudder

The Different Modes

Potentiometer
connections in
the transmitter
(Schematical
presentation
of the opened
radio)
Roll/Aileron
ON
1 2 3 4 5 6 7 8
DIP-switches (at the
transmitter rear case)
Roll/Aileron
ON
1 2 3 4 5 6 7 8
31
+ +
DIP
+ +
DIP
+ +
+ +
