30 | English
Changing the tool (see figure A)
Insert the screwdriver bit (1) directly into the tool holder (2).
Off-set Angle Adapter/Angle Screw Adapter/Torque Setting
Adapter (see figures B–E)
You can drive in screws close to edges using the off-set angle adapter (13).
The angle screw adapter (14) allows you to drive in screws in hard-to-reach
areas.
The torque presetting ring (16) on the torque setting adapter (15) can be
used to pre-select the required torque in 10 stages. When the correct set-
ting is used, the application tool will be stopped when the screw is driven
flush into the material or once the set torque has been reached.
Assembly (see figures B–C)
To fit the adapters, pull off the worklight cover (7) towards you. Then the ad-
apters can be attached. It is possible to fit an adapter offset by 45°.
Removal (see figures D–E)
To remove an adapter, turn the unlocking ring (23) in rotational direction ➊
and pull the adapter off towards you. Then reattach the worklight cover (7).
Operation
Starting Operation
Setting the Rotational Direction
The rotational direction switch (6) is used to change the rotational direction
of the power tool. However, this is not possible while the on/off switch (5) is
being pressed.
Clockwise: To drive in screws, press the rotational direction switch (6) all
the way to the left.
Anti-clockwise: To loosen or unscrew screws, press the rotational direction
switch (6) all the way to the right.
Switching on/off
To start the power tool, press and hold the on/off switch (5).
The worklight (3) lights up when the on/off switch (5) is lightly or fully
pressed, allowing the work area to be illuminated in poor lighting conditions.
