Quick RGBW Manuel D'installation Et D'emploi page 13

DIMMER RGBW - REV005A
Cablaggio cavi di comunicazione seriale
on
ON
off
F
To connect LDIM BUS RGBW dimmer to Quick
refer to the specific connection diagram at page 34.
Selections
The operating mode can be selected by DIP switch
6-position DIP switches for setting operating mode
Dip 1-3 = not enabled (reserved for other functions)
Dip 4 = Local/Remote mode
SELECT
Dip 5 e 6 = type of light
Rotary switches for setting device address (max. 99 modules)
ADDRESS
TLine DIP switch for connecting the load on the communication line in remote mode (last module)
SIGNALS
SIGNALS DIAGNOSTICS
INPUTS LED STATUS
On
n. 4+2
Off
OUTPUTS LED STATUS
On o Off
n. 4
Flashing
STATUS LED POWER IN - F1 and F2
On
n. 2
Off
STATUS LED CPU ACTIVITY (READY)
Flashing
n. 1 Off
On
QUICK SPA
Utilizzare un cavo di buona qualità adatto per la comunicazione seriale, twistato e
schermato. Rispettare la connessione dei segnali secondo le indicazione di cui sopra.
Terminate the line on the last module of the network by turning the Tline DIP
SWITCH "ON".
QNN device,
®
O
N 1 2 3 4 5 6
SELECT
Enabled
Not enabled
Output
Output protected against overcurrents and short circuits
Power supply connected
No power supply or blown fuse
CPU active and power supply connected
No power supply or CPU blocked
CPU blocked
13
OPERATION / SIGNALS
ON
ADDRESS TLine
Off = local / On = local and remote
5 and 6 Off = single-colour light
5 On and 6 Off = tunable white light
5 Off and 6 On = RGBW light
EN
