Parts List - MIRKA ROP2 Instructions D'utilisation

Item No. Part No.
1 MPA0040 RETAINING RING
2 MPA0021 BEARING
3 MPB0017 REAR ENDPLATE
4 MPB0118 ROTOR
5 MPA0445 VANE
6 MPA0041 WOODRUFF KEY
7 MPA0042 O-RING
8 MPA0441 CYLINDER ASSEMBLY
9 MPB0016 FRONT ENDPLATE
10 MPA0019 BEARING
11 MPA0045 O-RING
12 MPA0001 LOCK RING
MPB0203 77 mm (3 in.) x 12 mm (1/2 in.) ORBIT AirSHIELD™ SHAFT BALANCER (77 mm Machines)
13
MPC0381 125 mm (5 in.) x 12 mm (1/2 in.) ORBIT AirSHIELD™ SHAFT BALANCER (125 mm Machines)
14 MPA0122 FILTER
15 MPA0121 DUCKBILL CHECK VALVE
16 MPA0120 VALVE RETAINER
17 MPA0090 RETAINING RING
MPA0751 BEARING (125 mm Machines)
18
MPA0938 BEARING (77 mm Machines)
MPA0016 SPACER (77 mm Machines)
19
MPA1767 SPACER (125 mm Machines)
MPA0017 BELLEVILLE WASHER (77 mm Machines)
20
MPA1024 BELLEVILLE WASHER (125 mm Machines)
MPB0208 SPINDLE (125 mm Machines)
21
MPB0312 SPINDLE (77 mm Machines)
MPA0018 RETAINING RING (77 mm Machines)
22
MPA1025 RETAINING RING (125 mm Machines)
23 MPA1711 M8 THREADED PLUG
24 MPB0401 RH HOUSING
25 MPA2073 10,000 rpm 12.0 mm (1/2 in.) ORBIT THROTTLE LEVER - TwoHAND
26 MPA0068 MUFFLER INSERT
27 MPA1218 TOP HOUSING SEAL
28 MPA1255 NV LOWER HOUSING SEAL
29 MPA0004 CYLINDER SPRING PIN
30 MPA1865 SPACER RING
31 MPB0420 HANGER
32 MPB0356 MOTOR HOUSING
MPA2080 BUFFER SHROUD (125 mm Machines)
33
MPC0228 BUFFER SHROUD (77 mm Machines)
MPA0022 24 mm PAD WRENCH (125 mm Machines)
34
MPA0146 17 mm WRENCH (77 mm Machines)
35 N/A 1 Back-Up Pad supplied with each tool (type determined by model)
37 MPA0655 VALVE STEM ASSEMBLY
38 MPA0015 VALVE SLEEVE
39 MPA0009 VALVE SEAT
40 MPA0007 VALVE
41 MPA0014 VALVE SPRING
42 MPA0730 AIRLINE SEAL ASSEMBLY
43 MPA0500 EXHAUST GASKET
44 MPB0182 NV/CV EXHAUST NOZZLE
45 MPA0664 SCREW
46 MPA0517 EXHAUST TUBING
47 MPA0516 TUBING CLAMP
48 MPA0511 INLET TUBING
49 MPA0510 INLET CAPTIVE RING
50 MPA0509 O-RING
51 MPA0776 MUFFLER
52 MPA0628 O-RING
53 MPA0731 INLET/EXHAUST END CAP ASSEMBLY FOR NV MACHINES
54 MPA1398 SCREW
55 MPA0013 1/4-18 NPT INLET BUSHING ASSEMBLY
56 MPB0402 LH HOUSING
57 MPA1430 SCREW
58 MPA1981 SIDE HANDLE
59 MPA0043 O-RING
MPB0183 TwoHAND™ SPEED CONTROL
60
MPA1939 FLUSH TwoHAND SPEED CONTROL
61 MPA0039 RETAINING RING
62 MPA2541 FRONT BEARING DUST SHIELD
MPA2540 TwoHAND SPINDLE BEARING DUST SHIELD (125 mm Machines)
63
MPA2542 SPINDLE BEARING DUST SHIELD (77 mm Machines)

Parts List

Description
2
Qty.
1
1
1
1
5
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1
2
1
1
4
1
1
7
1
1
1
OPT
1
1
1
1
