ViewSonic PX749-4K Guide De Démarrage Rapide

PX749-4K
4K Home Projector
Quick Start Guide
クイックスタートガイド
http://vsweb.us
Download Link
http://vsweb.us/q/dn.php
ViewSonic Projector
4
O Of f
Auto
S c Source
ect P 3D
ID Set 1 2
t o t r
Tem
3 4 5
Sta ard
6 7 8
Eco ode
1
O Off
Auto Source
S c
PX749-4K
4K Home Projector
ect P 3D
Quick Start Guide
ID Set 1 2
クイックスタートガイド
t o t r
Tem
3 4 5
Sta ard
6 7 8
Eco
ode
http://vsweb.us
Download Link
http://vsweb.us/q/dn.php
ViewSonic Projector
5
312 mm
2
1 2
3
5
4
100-240 Vac
50/60 Hz
6
• 16:9 image on a 16:9 screen
221.9
mm
• 16:9 image on a 4:3 screen
103.9
mm
3
O Of f
O
Auto Source
S c
ect P 3D
ID Set 1 2
r
t o t Tem
3 4 5
Sta ard
6 7 8
Eco
ode
O Of f
Auto Source
S c
Source
ect P 3D
ID Set 1 2
r
t o t Tem
3 4 5
Sta ard
6 7 8
Eco
ode
DESIGNED FOR XBOX
For the lowest possible latency,
disable keystone/warp.
16:9 image on a 16:9 Screen
(a) Screen Size (b) Projection distance
(c) Image
height
m i . n m a . x
inch mm inch mm inch mm inch mm
60 1524 59 1496.8 77 1945.9 29 747
70 1778 69 1746.3 89 2270.2 34 872
80 2032 79 1995.8 102 2594.5 39 996
90 2286 88 2245.3 115 2918.8 44 1121
100 2540 98 2494.7 128 3243.2 49 1245
110 2794 108 2744.2 140 3567.5 54 1370
120 3048 118 2993.7 153 3891.8 59 1494
130 3302 128 3243.2 166 4216.1 64 1619
140 3556 138 3492.6 179 4540.4 69 1743
150 3810 147 3742.1 192 4864.7 74 1868
160 4064
157 3991.6 204 5189.1 78 1992
170 4318 167 4241.1 217 5513.4
83 2117
180 4572 177 4490.5 230 5837.7 88 2241
190 4826 187 4740.0 243 6162.0 93 2366
200 5080 196 4989.5 255 6486.3 98 2491
16:9 image on a 4:3 Screen
(a) Screen Size (b) Projection distance
(c) Image
height
m i . n m a . x
inch mm inch mm inch mm inch mm
60
1524 54 1373.9 70 1786.1 27 686
70
1778 63 1602.9 82 2083.8 32 800
80
2032 72 1831.9 94 2381.5 36 914
90
2286 81 2060.9 105 2679.1 41 1029
100 2540 90 2289.9
117 2976.8 45 1143
110
2794 99 2518.9 129 3274.5 50 1257
120
3048 108 2747.8 141 3572.2 54 1372
130
3302 117 2976.8 152 3869.9 59 1486
140
3556 126 3205.8 164 4167.6 63 1600
150
3810 135 3434.8 176 4465.2 68 1715
160
4064 144 3663.8 188 4762.9 72 1829
170
4318 153 3892.8 199 5060.6 77 1943
180
4572 162 4121.8 211 5358.3 81 2057
190
4826 171 4350.7 223 5656.0 86 2172
200
5080 180 4579.7 234 5953.6 90 2286
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should
physically test the projection size and distance using the actual projector in situ before
you permanently install it, so as to make allowance for this projector's optical
characteristics. This will help you determine the exact mounting position so that it best
suits your installation location.
On
(d) Vertical offset
m i . n m a . x
inch mm inch mm
2.9 74.7 2.9 74.7
3.4 87.2 3.4 87.2
3.9 99.6 3.9 99.6
4.4 112.1 4.4 112.1
4.9 124.5 4.9 124.5
5.4 137.0 5.4 137.0
5.9 149.4 5.9 149.4
6.4 161.9 6.4 161.9
6.9 174.3 6.9 174.3
7.4 186.8 7.4 186.8
7.8 199.2 7.8 199.2
8.3 211.7 8.3 211.7
8.8
224.1 8.8 224.1
9.3 236.6 9.3 236.6
9.8 249.1 9.8 249.1
(d) Vertical offset
m i . n m a . x
inch mm inch mm
2.7 68.6 2.7 68.6
3.2 80.0 3.2 80.0
3.6 91.4 3.6 91.4
4.1 102.9 4.1 102.9
4.5 114.3 4.5 114.3
5.0 125.7 5.0 125.7
5.4 137.2
5.4 137.2
5.9 148.6 5.9 148.6
6.3 160.0 6.3 160.0
6.8 171.5 6.8 171.5
7.2 182.9 7.2 182.9
7.7 194.3 7.7 194.3
8.1 205.7 8.1 205.7
8.6 217.2 8.6 217.2
9.0 228.6 9.0 228.6
