Fig. 
To switch off the battery together with the Bluetooth® function, press and hold the On/Off switch (2) for 8 s
until the LED (3) starts flashing in purple.
To switch off the battery leaving the Bluetooth® function active, press and hold the On/Off switch (2) for 4 s
until the LED (3) starts flashing in blue.
To deactivate the battery for a longer time (e.g. for storage), push the DIP switch 6 (1) into off position.
Shutting down by the smartphone application
Fig.  on page 6
1. Tap on the menu icon (1).
2. Tap on the Bluetooth® icon (2).
3. Tap on the battery disconnection icon (3).
The battery will switch off after a few seconds with the Bluetooth® function remaining active.
LED indications
LED indication
Green constantly lit
Green flashing
Blue flashing
Purple flashing
Red flashing
Orange flashing
Orange constantly lit
Off
Charging
When charging the battery with an external charger, observe the following guidelines:
• For best results use chargers intended for charging LiFePO4 batteries. If you do not have such a charger, you
can use lead-acid battery chargers.
• The charger must not perform any desulfation action.
• When using a configurable charger set the contant current/constant voltage (CC/CV) option with the follow-
ing values:
• Set the end of charge voltage to 14.4 V.
• Set the recommended maximum charging current for the battery.
• The maximum charging voltage should not exceed 14.5 V. If the charging voltage is 14.7 V ... 16 V the internal
battery management system (BMS) will limit the charge.
• If during charging the temperature raises above the permissible range, the internal battery management sys-
tem (BMS) will limit the charge to preserve battery life.
• At the end of the charging the charger can be disconnected, be turned off, or kept connected at float voltage.
Description
Battery starting up. No voltage is present at the terminals.
Battery active. Voltage is present at the terminals.
Battery powering down. Bluetooth® active. No voltage is present at the terminals.
Battery powering down. Bluetooth® not active. No voltage is present at the terminals.
Battery alarm. No voltage is present at the terminals.
Temperature range limit reached. Voltage is present at the terminals.
Firmware update.
Battery inactive. No voltage is present at the terminals.
