EN
6. Connect the positive terminals (6) of the batteries.
11 Wire and fuse sizing
In order to properly dimension wiring and fuses the distances and loads must be analysed. As it is not possible to
provide a unique figure valid for every application, the following examples are purely indicative.
Estimated maximum
consumption
20 A (refrigerator,
lights, water pump)
130 A (inverter with
coffee machine, and
hairdryer)
200 A (inverter with air
conditioner)
12 Operation
NOTE Always charge the battery completely before using it to its full potential.
Activation
The factory setting for the battery is the inactive mode: No voltage is present at the terminals. To use the battery it
must be activated and switched on.
1. Ensure that the DIP switch 6 (1) is set to the on position (factory setting).
If other devices are connected to the battery via the BUS (4), ensure that DIP switch 5 is set to the on position
(factory setting).
2. Press and hold the On/Off switch (2) for 1 s.
The battery is active when the LED (3) lights up.
Shutting down
The battery can be switched off in four different ways:
• With the display button
• With the On/Off switch
• With the DIP switch 6
• With the smartphone application
Fig.  on page 5
To switch off the battery on the display press and hold the button until the message "Shutdown" is displayed.
The battery will turn off with the Bluetooth® function remaining active.
14
Length ≤ 2 m
Maximum wire cross-section
Length 2 m ... 4 m
4 mm²
25 mm²
35 mm²
Fig.  on page 5
Length ≥ 4 m
6 mm² 10 mm²
35 mm² 50 mm²
50 mm² 70 mm²
Fuse
40 A
150 A
200 A
