Instructions for installation and use
10. Technical data
For the dimensions of the Concept R combi, refer to Fig. 5.
Article
number
CP-RC-090
CP-RCB-090
CP-RC-105
CP-RCB-105
Article
number
CP-RC-090
CP-RCB-090
CP-RC-105
CP-RCB-105
Fig. 5 Dimensions for Concept R combi 9 kW and 10.5 kW
WORLD OF WELLNESS
Power rating Power rating
of the heating of the evapo-
system [kW]
9,0
10,5
Weight without
stones [kg]
34
34
663
590
Cabin
volumes
[m 3 ]
rator [kW]
2,5 9 - 14
2,5 10 - 15
Stone
Fuse [A]
weight [kg]
ca. 25
ca. 25
Minimum size of
ventilation opening
[mm]
350 x 50
350 x 60
Supply voltage
3 x 16 400 VAC 3N~
50/60 Hz
3 x 16 400 VAC 3N~
50/60 Hz
523
450
Dimensions in mm
