4. Screw the sprinkler pipe ④ onto the intermediate piece.
5. Insert the screw ⑤ with the washer ⑥ and the O-ring ⑦ through the hole in the mounting bracket of
the UVC clarifier from the inside.
6. Tighten the UVC clarifier using the nut ⑨ and the washer ⑧.
LOOP10000/15000
1. Slip the sealing washer ② onto the thread of the UVC clarifier ①.
2. Insert the UVC clarifier through the opening in the filter housing.
3. Screw the T-intermediate piece ③ onto the UVC clarifier from the inside.
4. Screw the two sprinkler pipes ④ onto the T-intermediate piece.
5. Insert the screw ⑤ with the washer ⑥ and the O-ring ⑦ through the hole in the mounting bracket of
the UVC clarifier from the inside.
6. Tighten the UVC clarifier using the nut ⑨ and the washer ⑧.
Inserting the filter (⌦C)
LOOP5000/7000
1. Fill the included net with the EHEIM FILTERBIO granules (biological filter granules).
2. Insert the filter in the filter housing in the following order:
① Net with EHEIM FILTERBIO granules
Attention: The net must lie flat on the housing base
② Blue filter foam, fine
③ 2x Blue filter foam, coarse
LOOP10000/15000
1. Fill the EHEIM FILTERMEC granules (mechanical filter granules) ① loosely in the filter housing.
2. Insert the filter in the filter housing in the following order:
② Blue filter foam, fine
③ 2x Blue filter foam, coarse
Installing the pump connection (⌦D)
1. Place the sealing washer ③ between the screw connection on the housing and connecting piece ①.
2. Screw the connecting piece onto the screw connection with the union nut.
3. Connect the hose ③ to the connecting piece.
Connecting the outlet hose (⌦E)
1. Use a saw to shorten the outlet spigot to the diameter of your hose.
2. Connect your hose to the outlet spigot.
We recommend fastening the hoses with hose clamps.
Operation
DANGER! Electric shock!
▶ When the UVC clarifier is fitted, the device's safety distance from the water must be at least 2 m.
