37. Primer bulb
38. Choke lever
39. Full choke position
40. Run position
41. Blade protector
42. Clip
43. Air lter cover knob
44. Air lter cover
45. Filter
46. Spark plug cover
47. Spark Plug
48. Rear cover
49. Screw (T20 torx)
50. Screw (T25 torx)
51. Muf er gasket
52. Muf er
53. Spark arrestor
54. Plate
55. Screw (18 in.lb - 22 in.lb)
56. Heat shield
57. Screw (60 in.lb - 80 in.lb)
ASSEMBLY
SETTING UP THE HANDLE
See gure 2.
1. Loosen the knob.
2. Lift and rotate the handle to the desired position.
3. Tighten the knob securely.
NOTE: The product has a built-in micro-switch that
deactivates the engine if the knob is not fully tightened.
WARNING
Check the knob for tightness periodically to avoid
serious injury.

ATTACHING THE SHOULDER STRAP

See gure 3.
Connect the latch on the shoulder strap to the strap
hanger.
Adjust the shoulder strap hanger to a balanced
position where the blade or cutter attachment will
suspend between 100 mm to 300 mm above the
ground surface.
Adjust the strap hanger to a comfortable position.
NOTE: To quickly release the product from the shoulder
strap, sharply pull the quick release tab.
English(Original instructions)
ATTACHING THE BLADE GUARD AND GRASS
DEFLECTOR
See gure 4.
When using the string trimmer string head, the grass
de ector must be attached to the blade guard. When
using the brushcutter blade, the grass de ector must
be removed from the blade guard.
CONVERTING
BRUSHCUTTER
Removing the string head
See gure 5.
To reduce the risk of serious personal injury, always
stop the engine and remove the spark plug wire before
making any adjustments such as changing cutting
heads.
1. Open the ReelEasy™ string trimmer head by
2. Remove the string head cover, bump knob, and line
3. Remove the hex bolt from the drive shaft by using the
4. Remove the string head housing from the drive shaft.
5. Place the holding pin through the upper ange washer
6. Remove the upper ange washer from the gear shaft
7. Use the combination wrench supplied to loosen all 3
16
To attach the blade guard to the mounting bracket,
align the screw holes on the blade guard with the
bolts on the mounting bracket. Tighten the two bolts
securely with the combination wrench supplied.
NOTE: The blade guard should remain fitted to the
product at all times.
To attach the grass guard to the blade guard, align the
3 screws on the grass deflector with the screw holes
on the blade guard. Tighten all 3 screws securely with
the combination wrench supplied.
WARNING
FROM STRING
WARNING
depressing the latches on each side. The contents of
the bump head are spring loaded, so keep your other
hand over the string head cover while depressing the
latches.
spool.
hex-shaped opening on the inside of the string knob.
and the gear head. Using the 16 mm wrench supplied,
turn the drive connector clockwise to remove.
and retain for later use.
bolts, then remove the grass de ector from the blade
guard.
TRIMMER TO
