Ryobi RBC254FSB Manuel D'utilisation page 22

Wear non-slip safety footwear when
using this equipment.
Wear non-slip, heavy duty gloves.
Use unleaded petrol intended for motor
vehicle use with an octane rating of 91
[(R + M)/2] or higher.
Use 2-stroke oil for air cooled engines.
Mix the fuel mix thoroughly and also each
time before refuelling
CE Conformity
GOST-R Conformity
Tri-Arc blade
Blade thrust may occur without warning if
the blade snags, stalls or binds.
Wear eye and hearing protection when
operating this product.
Set the choke lever to "RUN" position.
Set the choke lever to "FULL" choke
position.
Set the choke lever to Full choke/Run
position
10
10
10
Set the ignition switch to the "I" (ON)
position.
Fully press and release the primer bulb
10 times.
Pull the starter grip until the engine
attempts to start.
Risk of getting a cut.
Lock the throttle in position by depressing
the throttle interlock button.
English(Original instructions)
DESCRIPTION
1. Starter grip
2. Foam handle
3. Strap hanger
4. Knob
5. Trigger handle
6. Throttle trigger
7. Throttle lock
8. Throttle interlock
9. Ignition switch
10. Bike handle
11. Left handle
12. Shaft
13. Gear head
14. Tri-Arc™ blade
15. Blade guard
16. Cutting line
17. Grass de ector
18. Line cut-off blade
19. Shoulder strap
20. Quick release tab
21. Latch
22. Wrench (16 mm)
23. Mounting bracket
24. Bolt (3/4 in.)
25. Screw hole
26. Screw
27. Screw hole
28. Drive connector
29. Upper ange washer
30. Holding pin
31. Cupped washer
32. Blade nut
33. Wrench (13 mm)
34. Dangerous cutting area
35. Direction of rotation
36. Best cutting area
15
Squeeze the throttle lock and throttle
trigger to run.
Starting a cold engine
Starting a warm engine
Direction of handle rotation
109 Guaranteed sound power level is 109 dB.
